PC 3.5 Straight Cable Plugs, Female

PC 3.5 Straight Cable Plugs, Female

PC3-eaaf2f

Enhance connectivity with PC 3.5 Straight Cable Plugs. 50 Ohm impedance, durable stainless steel body, and up to 33 GHz frequency support.

$39.99
$39.99
Sale

Initiate Order

PC 3.5 Straight Cable Plugs, Female

PC 3.5 Straight Cable Plugs, Female

$39.99

Quantity: 1

Claim Your Seller Account

PC 3.5 Straight Cable Plugs, Female

PC 3.5 Straight Cable Plugs, Female

$39.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
Enhance your connectivity with the PC 3.5 Straight Cable Plugs, Female. Featuring an impedance of 50 Ohms, RF leakage of over 100 dB, and a durable stainless steel body, these connectors ensure reliable performance. With a temperature range from -85 to 194 degrees F, they meet rigorous industry standards for quality and durability. Ideal for high-frequency applications up to 33 GHz.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Specifications Body Material
stainless steel
Specifications Cable Entries
brass
Specifications Cable Group
Y5, Y12
Specifications Cable Type
semi-rigid
Specifications Centre Contacts
beryllium-copper, hardened
Specifications Centre Contact Resistance M Ohms
<3
Specifications Configuration
straight
Specifications Connection
female
Specifications Connector Series
PC 3.5
Specifications Contact Captivation Lbs
>6.1
Specifications Coupling Nut Retention Force Lbs
>60.7
Specifications Dielectic Withstanding Voltage Sea Level V Rms
750/1000
Specifications Durability Matings
>500
Specifications Frequency Ghz
DC...33
Specifications Gaskets
silicone rubber
Specifications Impedance Ohms
50
Specifications Insulation Resistance M Ohms
>50000
Specifications Outside Contact Resistance M Ohms
<2
Specifications Packaging
single
Specifications Rf Leakage Db
>100
Specifications Support Beads
polystyrene, crosslinked
Specifications Temperature Range Degrees F
-85 to 194
Specifications Working Voltage Sea Level V Rms
<250/<335
