The versatile PC Mount Split Pack Power Transformers by Triad offer reliability and performance for PC board applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
PC Mount Split Pack Power Transformers
$29.99
Quantity: 1
Claim Your Seller Account
PC Mount Split Pack Power Transformers
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PC Mount Split Pack Power Transformers by Triad is a versatile solution for PC board applications. Featuring a split bobbin winding design with primaries and secondaries side-by-side, it eliminates costly electrostatic shielding. This transformer is available in a dual secondary configuration with single or dual primaries, offering an electrical rating of 12.0 VA. With hi-pot testing at 2,500 VRMS and precise PC terminal pin spacing for accurate placement, it ensures reliable performance. The transformer complies with industry standards, making it an ideal choice for both consumer and institutional buyers.
Product Specifications
Specifications Dimension A
0.30 in
Specifications Dimension B
0.40 in
Specifications Dimension C
1.410 in
Specifications Electrical Rating
12.0 V·A
Specifications Height H
1 7/16 in
Specifications Length L
1 7/8 in
Specifications Mounting Width
1 1/4 in
Specifications Number Of Pins
6
Specifications Primary Frequency
50 Hz | 60 Hz
Specifications Primary Voltage
115 V | 230 V
Specifications Secondary Voltage In Parallel
60.0 V at 0.2 A
Specifications Secondary Voltage In Series
120.0 V CT at 0.1 A
Specifications Transformer Contact Type
Center Tap
Specifications Type
Single Primary
Specifications Weight
0.70 lb
Specifications Width W
1 9/16 in
Technical Notes 0
Hi-pot tested at 2,500 VRMS.PC terminal pin spacing for accurate placement.115 V connect primary in parallel.230 V connect primary in series.Series Connections:Primary - Input 1 & 4Connect 2 & 3Secondary - Input 5 & 8Connect 6 & 7Parallel Connections:Primary - Input 1 & 2Connect 1 & 3. 2 & 4Secondary - Input 5 & 8Connect 5 & 7, 6 & 8For single primary, omit pins 2 and 3.1.1 & 2.5 VA are not offered with mounting holes.
