PC Mount Split Pack Power Transformers - Dual Secondary
PC Mount Split Pack Power Transformers - Dual Secondary
SKU:POW-83fc38
Versatile PC Mount Split Pack Power Transformers - Ideal for PC board applications with split bobbin design and dual secondary configuration. Hi-pot tested for reliability.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
PC Mount Split Pack Power Transformers - Dual Secondary
$24.99
Quantity: 1
Claim Your Seller Account
PC Mount Split Pack Power Transformers - Dual Secondary
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PC Mount Split Pack Power Transformers are a versatile solution for PC board applications. Featuring a split bobbin design, these transformers eliminate costly electrostatic shielding thanks to their nonconcentric winding. With dual secondary configuration options and single or dual primaries, they offer flexibility and efficiency in power supply setups. The Triad Split Pack transformers are hi-pot tested at 2,500 VRMS, ensuring reliable performance. Designed with precise PC terminal pin spacing for accurate placement, these transformers meet the needs of both consumer and institutional buyers seeking top-tier power solutions.
Product Specifications
Specifications Dimension A
0.30 in
Specifications Dimension B
0.40 in
Specifications Dimension C
1.410 in
Specifications Electrical Rating
12.0 V·A
Specifications Height H
1 7/16 in
Specifications Length L
1 7/8 in
Specifications Mounting Width
1 1/4 in
Specifications Number Of Pins
6
Specifications Primary Frequency
50 Hz | 60 Hz
Specifications Primary Voltage
115 V | 230 V
Specifications Secondary Voltage In Parallel
14.0 V at 0.84 A
Specifications Secondary Voltage In Series
28.0 V CT at 0.42 A
Specifications Transformer Contact Type
Center Tap
Specifications Type
Single Primary
Specifications Weight
0.70 lb
Specifications Width W
1 9/16 in
Technical Notes 0
Hi-pot tested at 2,500 VRMS.PC terminal pin spacing for accurate placement.115 V connect primary in parallel.230 V connect primary in series.Series Connections:Primary - Input 1 & 4Connect 2 & 3Secondary - Input 5 & 8Connect 6 & 7Parallel Connections:Primary - Input 1 & 2Connect 1 & 3. 2 & 4Secondary - Input 5 & 8Connect 5 & 7, 6 & 8For single primary, omit pins 2 and 3.1.1 & 2.5 VA are not offered with mounting holes.
