PeeWee Series 12kVDC Single Pin Cable Assembly (Rear Mount)
PeeWee Series 12kVDC Single Pin Cable Assembly (Rear Mount)
SKU:HIG-947193
Reliable 12kVDC Single Pin Cable Assembly for high voltage applications. Silicone rubber encapsulation, altitude rating up to 70,000 ft.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
PeeWee Series 12kVDC Single Pin Cable Assembly (Rear Mount)
$49.99
Quantity: 1
Claim Your Seller Account
PeeWee Series 12kVDC Single Pin Cable Assembly (Rear Mount)
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience high voltage connectivity at its finest with our PeeWee Series 12kVDC Single Pin Cable Assembly. Designed for dense electronic packaging, this assembly offers a reliable push-pull coupling style, operating seamlessly in temperatures ranging from -55 to 125°C. With a test voltage of 18kVDC and altitude tolerance of up to 70,000 ft, this non-shielded assembly is encapsulated with silicone rubber for added durability. Ideal for power supplies, photomultipliers, lasers, and TWT applications.
Product Specifications
Application 0
Power SuppliesPhotomultipliersLasersTWT
Body Properties Coupling Nut Material
Plastic
Cable Wire Properties Wire Diameter
0.050 in
Contact Properties Contact Diameter
0.030 in | 0.762 mm
Contact Properties Contact Size
24 AWG
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Right Angle Receptacle Single Ended Cable Assembly
Specifications Coupling Style
Push-Pull
Specifications Current Rating
1.6 Amp
Specifications Encapsulation
Back end of connector is encapsulated with silicone rubber
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Mating Compatibility
Mates with all threaded Pee-Wee series coupling plug cable assemblies.
Specifications Operating Temperature
-55 to 125 ºC
Specifications Panel Mounting Style
Rear Mount
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
No
Specifications Series
PeeWee
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
18 kVDC
Specifications Voltage Rating
12 kVDC
Specifications Wire Insulation
Etched FEP
