The PENCOM 3.25mm Self-Clinching Standoff is designed for precise panel spacing. With a self-clinching design for permanent installation in thin sheets, this standoff offers RoHS compliant options. Its miniature threads and body diameters cater to small-scale applications, ensuring reliable and durable performance.
Product Specifications
Dimensions Anvil Dimensions
Standoff C Dimension - 3.23 Millimeter (mm)A +0.08/-0.00 - 3.28 Millimeter (mm)B +0.18/-0.00 - 3.96 Millimeter (mm)
Dimensions C 00 13
3.23 mm
Dimensions D Minimum Thread Depth
3.9 mm
Dimensions H Nom
3.96 mm
Dimensions L Length 08
8.00 mm
Dimensions Minimum Distance From Sheet Hole Center To Edge
4.8 mm
Dimensions Min Sheet Thickness
.63 mm
Dimensions Sheet Hole Size 08 00
3.25 mm
Dimensions Thread Code
M2
Dimensions Thread Size
M2 x .4
Material And Finish Finish
Plain
Material And Finish Material
Aluminum
Material And Finish Material Code
AL
Material And Finish Maximum For Use In Sheet Hardness
50 Rockwell B
Note For Performance Note For Performance
Performance data represents the average destructive result for standoffs only when all installation specifications are strictly followed. Variations in panel hole size, thickness, material, and installation methods will affect the loads. PENCOM strongly encourages testing the application.
Note Note For Length
Custom Lengths And Type Combinations Available By Request
Performance 63 Millimeter Mm 5052 H34 Aluminum Installation
4.0 kN
Performance 63 Millimeter Mm 5052 H34 Aluminum Push Out
267 N
Performance 63 Millimeter Mm 5052 H34 Aluminum Torque Out
.51 nm
Performance 63 Millimeter Mm Cold Rolled Steel Installation
Not Recommended kN
Performance 63 Millimeter Mm Cold Rolled Steel Push Out
Not Recommended N
Performance 63 Millimeter Mm Cold Rolled Steel Torque Out
Not Recommended nm
Performance Test Sheet Material
.63 Millimeter (mm) 5052-H34 Aluminum | .63 Millimeter (mm) Cold-Rolled Steel
Specifications Industry Standardscertifications
Restriction of Hazardous Substances (RoHS)
