PerMix PCH 5000 Shear Pump
PerMix PCH 5000 Shear Pump
SKU:PCH-558171
Enhance your processing efficiency with the PerMix PCH 5000 Shear Pump - the perfect blend of power and hygiene.
Regular price
$6,999.99
Regular price
Sale price
$6,999.99
Unit price
per
Initiate Order
PerMix PCH 5000 Shear Pump
$6,999.99
Quantity: 1
Claim Your Seller Account
PerMix PCH 5000 Shear Pump
$6,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PerMix PCH 5000 Shear Pump is a premium solution that seamlessly combines the efficiency of a centrifugal pump with the power of an inline high shear mixer. Crafted from stainless steel, it offers unmatched hygiene for applications in dairy, food, cosmetics, and pharmaceutical industries. With a maximum liquid capacity of 5000 L/h and a maximum powder capacity of 3 kg/min, this pump ensures optimal performance while maintaining a high level of shearing energy. Its compact design, CIP compatibility, and versatile stator rotor options make it a top choice for institutions seeking quality and efficiency.
Product Specifications
Additional Information Additional Information
PerMix Shear Pump can be easily cleaned with CIP (Clean In Place) system to save time and labor.By installing an optional hopper or a feeding table, PerMix Shear Pump is converted to a Powder Liquid Mixer, to be able to dissolve/disperse free flowing powder material into light liquid in a quite fast and efficient way.
Applications Applications
Some typical applications of PCH Shear Pumps:Food & BeverageButter, Canned foods, Cheese, Condiments, Dairy, Dressings, Flavorings, Ice cream, Juices, Ketchup, Salads, Syrup, YogurtPharmaceuticalsCough syrup, Emulsion, Medicine, Ointment, Pharmaceutical, Vaccine, Veterinary drugCosmeticsCreams, Detergent, Gels, Hair conditioner, Lotions, Shampoo, Tooth paste
Features And Options Features And Options
PCH Shear Pump is ideal for diary, beverage, food and other hygienic applications, with the following features and options:Compact and streamlined designAll built in stainless steel, with a stainless steel motor shroudEasy assembly and disassemblyFree flow powder induction, high efficiency, free of lumps and fish-eyes90% process time reduction compared with conventional agitator mixingCIP availableInterchangeable stator rotor of various type for different purposes (Option)
Note Note
Actual liquid/powder capacity will vary depending on the material characters and stator rotor type.PerMix offers bigger capacity according to customer requests.PerMix reserves the right to modify the design without notice.
Specifications Inlet Size
40 mm
Specifications Maximum Liquid Capacity
5000 L/h
Specifications Maximum Powder Capacity
3 kg/min
Specifications Motor Power
3 to 4 kW
Specifications Outlet Size
32 mm
Specifications Speed Of Mixing Can
3000 rpm
