The Petersen 938-96 Series 12-Inch Deflection Gauge with Aluminum Fins is designed to test flexible sewer pipes for out-of-roundness and deflection adherence per ASTM specifications D3034 and F679. Ensuring proper bedding and backfilling (ASTM D2321), this gauge features a nine-arm design for accurate testing while allowing easy passage of gravel and debris. Lightweight, corrosion-resistant, and field-verifiable without a proving ring, this gauge meets ASTM requirements and fits through standard 24 manholes. With fins designed to prevent tipping in the line and stringer compatibility for quick line stringing between manholes, this gauge guarantees optimal performance and compliance with industry standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Fits Connection Type
F375C
Specifications Flow Area
0.012 in² | 7.74 mm²
Specifications Inside Diameter Tube
0.125 in | 3.18 mm
Specifications Outside Diameter Tube
3/8 in | 9.53 mm
Specifications Toleranceoutside Diameter
.370/.365 in | 9.40/9.27 mm
Specifications Tube Materials
HP-160
Specifications Wall Thickness Tube
0.125 in | 3.18 mm
Specifications Working Pressure At 200f 93c
100000 psi | 6894.64 bar
Specifications Working Pressure At 325 To 100f 198 To 378c
100000 psi | 6894.64 bar
Specifications Working Pressure At 400f 204c
96210 psi | 6633.24 bar
Specifications Working Pressure At 600f 316c
90368 psi | 6230.55 bar
Specifications Working Pressure At 800f 427c
84420 psi | 5820.46 bar
