PLG Series 64 Reduction Ratio Gearbox with 6 Nm Torque
PLG Series 64 Reduction Ratio Gearbox with 6 Nm Torque
SKU:PLG-65f0f8
Compact and powerful PLG Series 64 Gearbox with 6 Nm torque, dual ball bearings, and high efficiency for industrial use.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
PLG Series 64 Reduction Ratio Gearbox with 6 Nm Torque
$299.99
Quantity: 1
Claim Your Seller Account
PLG Series 64 Reduction Ratio Gearbox with 6 Nm Torque
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PLG Series 64 Reduction Ratio Gearbox offers exceptional performance for industrial applications. With a reduction ratio of 64 and continuous torque up to 6 Nm, this gearbox ensures high efficiency, durability, and compact design. Featuring dual ball bearings on the output shaft and straight toothing across all stages, it guarantees reliable operation and minimal maintenance requirements. Ideal for applications requiring low weight, high torque, and vibration resistance.
Product Specifications
Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationFood grade lubricationLow temperatureHigh efficiencyHigh torqueSpecial surface availableVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
0 to 6 N·m
Technical Specs Efficiency
81 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
2
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Up to Ingress Protection (IP50)
Technical Specs Radial Load
250 N
Technical Specs Reduction Ratio
64
Technical Specs Ring Gear Material
Steel
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.37 kg
