PLG Series Compact Planetary Gearbox with 32:1 Reduction Ratio and 6 N·m Continuous Torque

PLG Series Compact Planetary Gearbox with 32:1 Reduction Ratio and 6 N·m Continuous Torque

PLG-f56778

Dunkermotoren PLG Series 32:1 Reduction Ratio Gearbox: High torque, compact design, lifetime lubrication.

$249.99
$249.99
Sale

Initiate Order

PLG Series Compact Planetary Gearbox with 32:1 Reduction Ratio and 6 N·m Continuous Torque

PLG Series Compact Planetary Gearbox with 32:1 Reduction Ratio and 6 N·m Continuous Torque

$249.99

Quantity: 1

Claim Your Seller Account

PLG Series Compact Planetary Gearbox with 32:1 Reduction Ratio and 6 N·m Continuous Torque

PLG Series Compact Planetary Gearbox with 32:1 Reduction Ratio and 6 N·m Continuous Torque

$249.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The PLG Series 32:1 Reduction Ratio Gearbox delivers exceptional performance for industrial applications. With an efficiency of 81% and a continuous torque of up to 6 N·m, this gearbox boasts dual ball bearings on its output shaft and straight toothing on all stages. Designed by Dunkermotoren, this compact gearbox offers a lightweight solution with high torque, high efficiency, and vibration resistance. Ideal for applications requiring lifetime lubrication and food-grade compatibility, the PLG Series ensures reliability and durability.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Additional Information Additional Information
Planetary gearboxes (PLG) have the highest continuous torque capacity of all types of gearbox; at the same time they have a very compact design, low weight and excellent gear efficiency of typically 97%. For our planetary gearboxes there are, depending on customer requirements, a variety of different materials combinable, whereby continuous torques reach up to 130 Nm, and ratios from 4:1 to 512:1 are available. The planetary gearboxes are maintenance-free.
Features Features
Lifetime lubricationFood grade lubricationLow temperatureHigh efficiencyHigh torqueSpecial surface availableVibration resistance
Technical Specs Axial Load
150 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
0 to 6 N·m
Technical Specs Efficiency
81 %
Technical Specs Note For Axialradial Load
From center of shaft
Technical Specs Number Of Stages
2
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Up to Ingress Protection (IP50)
Technical Specs Radial Load
250 N
Technical Specs Reduction Ratio
32
Technical Specs Ring Gear Material
Steel
Technical Specs Series
PLG
Technical Specs Weight Of Gearbox
0.37 kg
