The PN 16 Cast Steel Overboard Spring-loaded Angle Valve offers premium durability and performance for industrial applications. Constructed with Cast Steel body, Stainless Steel disc, and stem, it ensures reliable operation. With DIN2501-PN16 compliant flanges and brass seat material, this valve meets stringent industry standards for safety and efficiency.
Product Specifications
Specifications Actuators
Spring
Specifications Body Material
Cast Steel
Specifications Connection
Flanged Drilled
Specifications D
460 mm
Specifications D2
395 mm
Specifications Disc Material
Stainless Steel
Specifications H1
1180 mm
Specifications Hydraulic Inspection Body
16
Specifications Hydraulic Inspection Seat
10
Specifications L1
375 mm
Specifications Seat Material
Brass
Specifications Size
300
Specifications Stem Material
Brass
Specifications Weight
360 kg
