PN 16 Ductile Iron Globe SDNR Valve - DIN Certified

Name: PN 16 Ductile Iron Globe SDNR Valve - DIN Certified
Brand: World Wide Metric, Inc.
SKU: VAL-b561c4
Price: 179.99 USD
Availability: OutOfStock

SKU:VAL-b561c4

Premium PN 16 Ductile Iron Globe SDNR Valve - DIN Certified, optimal for institutional applications.

$179.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The PN 16 Ductile Iron Globe SDNR Valve is a robust and reliable valve designed for a range of applications. Constructed with Ductile Iron body, Stainless Steel disc, and seat materials, this valve ensures durability and corrosion resistance. With a size of 050 and hydraulic inspections exceeding industry standards, it offers optimal performance. The valve's compliance with DIN 17672 specifications, ISO5752 Series 1 for Face to Face dimensions, and DIN2501-PN16 for flanges makes it suitable for institutional requirements.

Product Specifications

Specifications Actuators

Handwheel

Specifications Body Material

Ductile Iron

Specifications C

125 mm

Specifications Connection

Flanged Drilled

Specifications D

165 mm

Specifications D2

150 mm

Specifications Disc Material

Stainless Steel

Specifications H

260 mm

Specifications Hydraulic Inspection Body

Specifications Hydraulic Inspection Seat

Specifications L

230 mm

Specifications Number Of Holes

Specifications Seat Material

Stainless Steel

Specifications Size

050

Specifications Stem Material

Stainless Steel

Specifications T

18 mm

Specifications Weight

13.5 kg
