PN 160 Cast Steel Globe Valve
PN 160 Cast Steel Globe Valve
SKU:VAL-65f6ba
Durable PN 160 Cast Steel Globe Valve for precise hydraulic control, featuring Stellited seat and Stellite stem for corrosion resistance.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
PN 160 Cast Steel Globe Valve
$349.99
Quantity: 1
Claim Your Seller Account
PN 160 Cast Steel Globe Valve
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PN 160 Cast Steel Globe Valve is crafted for durability and precision. With a body made from GSC-25N2 Cast Steel, a stem of AISI 4103 Stainless Steel, and a Stellited disc, this valve ensures long-lasting performance. It meets ISO5752 face to face dimensions and DIN2501-PN160 flange requirements, guaranteeing seamless integration. Ideal for hydraulic applications, its Stellited seat and Stellite stem offer superior corrosion resistance and reliability.
Product Specifications
Specifications Actuators
Handwheel
Specifications Body Material
Cast Steel
Specifications C
125 mm
Specifications Connection
Flanged Drilled
Specifications D
170 mm
Specifications D2
200 mm
Specifications Disc Material
Stellited
Specifications H
350 mm
Specifications Hydraulic Inspection Body
240
Specifications Hydraulic Inspection Seat
160
Specifications Impaissa Code
755436
Specifications L
260 mm
Specifications Number Of Holes
4
Specifications Seat Material
Stainless Steel
Specifications Size
040
Specifications Stem Material
Stellite
Specifications T
28 mm
Specifications Weight
23.0 kg
