PN 40 Cast Steel Lift Check Angle Pattern Valve - DIN 3202 Standard
PN 40 Cast Steel Lift Check Angle Pattern Valve - DIN 3202 Standard
SKU:VAL-892312
High-performance PN 40 Cast Steel Lift Check Angle Valve for industrial fluid control.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
PN 40 Cast Steel Lift Check Angle Pattern Valve - DIN 3202 Standard
$299.99
Quantity: 1
Claim Your Seller Account
PN 40 Cast Steel Lift Check Angle Pattern Valve - DIN 3202 Standard
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PN 40 Cast Steel Lift Check Angle Pattern Valve is designed for robust performance in industrial settings, featuring a Cast Steel body, Stainless Steel disc, seat, and stem materials, ensuring durability and corrosion resistance. Compliant with DIN 3202 standards, this valve offers reliable fluid control with precise dimensions adhering to DIN 2501-PN40 flange specifications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Actuators
Handwheel
Specifications Body Material
Cast Steel
Specifications C
125 mm
Specifications Connection
Flanged Drilled
Specifications D
165 mm
Specifications Disc Material
Stainless Steel
Specifications H
18 mm
Specifications Hydraulic Inspection Body
60
Specifications Hydraulic Inspection Seat
40
Specifications L1
125 mm
Specifications Number Of Holes
4
Specifications Seat Material
Stainless Steel
Specifications Size
050
Specifications Stem Material
Stainless Steel
Specifications T
20 in
Specifications Weight
13.0 kg
