PN 40 Cast Steel Quick Closing Angle Valve 125mm
PN 40 Cast Steel Quick Closing Angle Valve 125mm
SKU:VAL-46cfcf
High-performance PN 40 Cast Steel Quick Closing Angle Valve - ideal for industrial applications. DIN2501-PN40 compliant.
Regular price
$589.99
Regular price
Sale price
$589.99
Unit price
per
Initiate Order
PN 40 Cast Steel Quick Closing Angle Valve 125mm
$589.99
Quantity: 1
Claim Your Seller Account
PN 40 Cast Steel Quick Closing Angle Valve 125mm
$589.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PN 40 Cast Steel Quick Closing Angle Valve is a robust solution for industrial applications requiring reliable shut-off capabilities. Constructed with durable Cast Steel body and Stainless Steel components, including the disc, seat, and stem, this valve ensures high performance under high pressure environments. With a Spring Loaded Shut-off Pressure of 1.2 bar and a Working Pressure of 40 bar, this valve offers secure operation. Compliant with DIN2501-PN40 standards, the valve comes with flanges for easy installation and features a lever actuator for convenient operation.
Product Specifications
Specifications Actuators
Lever
Specifications Body Material
Cast Steel
Specifications Connection
Flanged Drilled
Specifications D
250 mm
Specifications D2
160 mm
Specifications Disc Material
Stainless Steel
Specifications H1
530 mm
Specifications L1
200 mm
Specifications Seat Material
Stainless Steel
Specifications Size
125
Specifications Spring Loaded Shut Off Pressure
1.2 bar
Specifications Stem Material
Stainless Steel
Specifications Weight
71 kg
Specifications Working Pressure
40 bar
