High-performance PN 40 Cast Steel Quick Closing Angle Valve for industrial fluid control applications. DIN2501-PN40 flanges for superior reliability.
Regular price
$199.99
Regular price
Sale price
$199.99
Unit price
per
Initiate Order
PN 40 Cast Steel Quick Closing Angle Valve - DIN Specialty Valve
$199.99
Quantity: 1
Claim Your Seller Account
PN 40 Cast Steel Quick Closing Angle Valve - DIN Specialty Valve
$199.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PN 40 Cast Steel Quick Closing Angle Valve is a robust solution crafted from high-quality materials - Cast Steel body, Stainless Steel disc, seat, and stem. Designed for precision, it features spring-loaded shut-off pressure of 2.0 bar and a working pressure of 40 bar. With precise DIN2501-PN40 flanges, this valve offers reliability and longevity in industrial settings, making it ideal for fluid control applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Actuators
Lever
Specifications Body Material
Cast Steel
Specifications Connection
Flanged Drilled
Specifications D
105 mm
Specifications D2
100 mm
Specifications Disc Material
Stainless Steel
Specifications H1
290 mm
Specifications L1
95 mm
Specifications Seat Material
Stainless Steel
Specifications Size
020
Specifications Spring Loaded Shut Off Pressure
2.0 bar
Specifications Stem Material
Stainless Steel
Specifications Weight
7.0 kg
Specifications Working Pressure
40 bar
