Podis LED Industrial Lamp 24VDC
Podis LED Industrial Lamp 24VDC
SKU:POD-97fc59
Powerful 5W LED industrial lamp for harsh environments with IP65 protection and DIN standards compliance.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Podis LED Industrial Lamp 24VDC
$39.99
Quantity: 1
Claim Your Seller Account
Podis LED Industrial Lamp 24VDC
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Illuminate your industrial environment with the Podis LED Industrial Lamp. This 5W energy-saving luminaire is designed for harsh conditions like wind turbines, with a typ. 360lm output. It features reverse polarity protection, overload protection, and shortage protection. With an IP65 rating, operating temperatures ranging from -40°C to +70°C, and compliance with DIN 60598-1 standards, this lamp ensures reliability and safety in industrial settings.
Product Specifications
Classification Eclass 81 Classification
27110640
Classification Etim 40 Classification
EC001959
Classification Etim 50 Classification
EC001959
Classification Etim 60 Classification
EC001959
Classification Etim 70 Classification
EC001959
Classification Etim 80 Classification
EC001959
Classification Etim 90 Classification
EC001959
Dimensions Height
96 mm
Dimensions Length
160 mm
Dimensions Width
104 mm
General Brands
Wieland
General Circuit
Other
General Color Housing
Light Gray
General Degree Of Protection Ip
IP66 | IP67 | IP69
General Housing Material
Plastic
General Lamp
Light Emitting Diode (LED)
General Lamp Holder
Other
General Mounting Method
Wall
General Power Supply Connection
Plug Connection Reference, Secondary, and Tertiary (RST)
General Wiring System
Continuous Circuit | Standby Circuit
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant/Exempted
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Direct Current Dc Voltage
24 V
Technical Data Emergency Lighting Characterization
Z 1 ***D
Technical Data Fuse Current
0.5 A
Technical Data Fuse Voltage
60 V (Resetting)
Technical Data Lamp Power
4.9 W
Technical Data Light Color
6500 K
Technical Data Maximum Ambient Operating Temperature
70 ºC
Technical Data Maximum Nominal Voltage
32 V
Technical Data Maximum Storagetransport Temperature
70 ºC
Technical Data Minimum Ambient Operating Temperature
-40 ºC
Technical Data Minimum Nominal Voltage
15 V
Technical Data Minimum Storagetransport Temperature
-40 ºC
Technical Data Mode
Constant Current
Technical Data Reverse Polarity Protection
Yes
Technical Data Standards
DIN EN60598-1 | DIN EN60598-22
