Podis LED Lamp - Industrial Grade 24VDC 5W LED Luminaire
Podis LED Lamp - Industrial Grade 24VDC 5W LED Luminaire
SKU:POD-1e6229
Energy-efficient 5W LED lamp for industrial use in harsh environments, IP65-rated, -40°C to +70°C operating temperature
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Podis LED Lamp - Industrial Grade 24VDC 5W LED Luminaire
$49.99
Quantity: 1
Claim Your Seller Account
Podis LED Lamp - Industrial Grade 24VDC 5W LED Luminaire
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Illuminate your industrial spaces with the Podis LED Lamp designed for harsh environments like wind turbines. This energy-saving 5W lamp delivers 360 lumens of daytime white light at 6500K. With integrated protections against reverse polarity, overload, and shortages, it ensures reliability under extreme conditions. This IP65-rated lamp operates between -40°C to +70°C, meeting DIN and cURus standards for safety and performance.
Product Specifications
Classification Eclass 81 Classification
27110640
Classification Etim 40 Classification
EC001959
Classification Etim 50 Classification
EC001959
Classification Etim 60 Classification
EC001959
Classification Etim 70 Classification
EC001959
Classification Etim 80 Classification
EC001959
Classification Etim 90 Classification
EC001959
Dimensions Height
96 mm
Dimensions Length
160 mm
Dimensions Width
104 mm
General Brands
Wieland
General Color Housing
Light Gray
General Degree Of Protection Ip
IP65
General Housing Material
Plastic
General Lamp
Light Emitting Diode (LED)
General Mounting Method
Screwable
General Power Supply Connection
Plug Connection Reference, Secondary, and Tertiary (RST)
General Wiring System
Continuous Circuit | Standby Circuit
Product Compliance Certificationapproval
Det Norske Veritas (Norway) and Germanischer Lloyd (Germany) | Underwriters Laboratories (UL) | Underwriters Laboratories Recognized for Canada and United States (cRUus)
Product Compliance Reach Svhc Cas Numbers
7439-92-1
Product Compliance Reach Svhc Conformity Status
Duty-To-Declare
Product Compliance Reach Svhc Substances
Lead
Product Compliance Rohs Conformity Status
Compliant/Exempted
Product Compliance Rohs Exceptions
III-6(c)
Technical Data Direct Current Dc Voltage
24 V
Technical Data Emergency Lighting Characterization
Z 1 ***DE
Technical Data Fuse Current
0.5 A
Technical Data Fuse Voltage
60 V (Resetting)
Technical Data Lamp Power
4.9 W | 450 lm
Technical Data Light Color
5700 K
Technical Data Maximum Ambient Operating Temperature
70 ºC
Technical Data Maximum Nominal Voltage
30 V
Technical Data Maximum Storagetransport Temperature
70 ºC
Technical Data Minimum Ambient Operating Temperature
-40 ºC
Technical Data Minimum Nominal Voltage
15 V
Technical Data Minimum Storagetransport Temperature
-40 ºC
Technical Data Mode
Constant Current
Technical Data Reverse Polarity Protection
Yes
Technical Data Standards
DIN EN60598-1 | DIN EN60598-22
