Poly-Dies Press Brake Tool - Set of PUD-112 Poly-Dies
Poly-Dies Press Brake Tool - Set of PUD-112 Poly-Dies
SKU:PRE-c84e19
Achieve precise and efficient 90-degree bends with PUD-112 Press Brake Poly-Dies. Ideal for U-bend fabrication in one hit, compatible with ASTM Steel C-Channels.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Poly-Dies Press Brake Tool - Set of PUD-112 Poly-Dies
$99.99
Quantity: 1
Claim Your Seller Account
Poly-Dies Press Brake Tool - Set of PUD-112 Poly-Dies
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PUD-112 Press Brake Poly-Dies are precision-engineered for efficient sheet metal bending operations. With a pad width and height of 2.25 inches and a 1.50-inch hole diameter, these Poly-Dies are designed to deliver precise 90-degree bends up to 16-gauge capacity. The Poly-Dies feature a 3/8-inch size for 90-degree radius bends, making them ideal for U-bend fabrication in one hit. Compatible with ASTM Steel C-Channels, these square or rectangular pads are molded with a U-shaped top surface for seamless 180-degree U-bends. Ensure optimal performance and accuracy in your bending applications with the CR2222 Retainer Part Number for secure fit and stability.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Gauge Cap For 90 V
16 ga
Specifications Hole Diameter
1.50 in
Specifications Number Of Forming Surfaces
1
Specifications Pad Height
2.25 in
Specifications Pad Width
2.25 in
Specifications Puds For Radius U Bends
PUDs are designed to fit in standard ASTM Steel C-Channels, to function as holders or Retainers | PUDs are square or Rectangular shaped Pads with a molded U-Shaped top surface to enable 180 degrees U-Bends in one hit.
Specifications Retainer Part Number
CR2222
Specifications Size For 90 Radius
3/8 in
