Polypro Gauge Isolator with Economy 2.5" Vacuum Gauge
Polypro Gauge Isolator with Economy 2.5" Vacuum Gauge
SKU:GAU-c8960f
Protect & isolate instruments with Polypro Gauge Isolator & reliable 2.5" Vacuum Gauge. Accurate, durable & low maintenance design.
Regular price
$163.50
Regular price
Sale price
$163.50
Unit price
per
Initiate Order
Polypro Gauge Isolator with Economy 2.5" Vacuum Gauge
$163.50
Quantity: 1
Claim Your Seller Account
Polypro Gauge Isolator with Economy 2.5" Vacuum Gauge
$163.50
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Polypro Gauge Isolator with Economy 2.5" Vacuum Gauge is a reliable solution for protecting and isolating pressure sensing instruments in industrial settings. Featuring an impermeable EPDM diaphragm and a sturdy 1/2" Female NPT Inlet Connection, this isolator ensures accurate pressure transmission. The reinforced stainless steel instrument connection and compressive spoke ribs guarantee durability and optimal performance. With a low profile design that eliminates dead volume and a convoluted diaphragm for precise pressure containment, this isolator offers total isolation from system media. Easy to install and maintain, it comes with a 3-year limited warranty for added peace of mind.
Product Specifications
Features 0
Protects and isolates pressure sensing instruments Total isolation from system media Low profile design eliminates dead volume Convoluted diaphragm allows accurate transmission of system pressure Optimum pressure containment spherical design Low in original cost and maintenance Simple installation
Materials Of Construction 0
Body: PVC: Polyvinyl Chloride CPVC: Chlorinated Polyvinyl Chloride PP: Polypropylene homopolymer, glass & mineral reinforced Membrane: Standard: PTFE, also available in: FPM: Viton®, Fluorine elastomer EPDM: Ethylene Propylene elastomer
Scope 0
The Marquest Gauge Isolator provides two fluid chambers separated by an impermeable membrane. The upper chamber (instrument side) is normally filled with a stabilized liquid. The lower chamber receives the media under pressure. Most pressure sensing devices are compatible with 1/4" FNPT outlet. The inlet is standard 1/2" FNPT or 1/4" FNPT. Chemical resistance and purity levels are as recommended for the base materials. No metals or lubricants are used in construction, internally or externally. Custom membranes may be supplied upon request.
Specifications Inlet Connection
1/2" Female NPT
Specifications Installed Gauge
0-30 in-Hg Vac, Brass, Blk Pntd Steel
Specifications List Price
163.5 USD
Specifications Materials
PP, EPDM Diaphragm
Specifications Shipping Note
We will let you know the shipping charges once we receive the order.
