Polypro Gauge Isolator with Wika Stainless Brass Gauge
Polypro Gauge Isolator with Wika Stainless Brass Gauge
SKU:GAU-b6c714
Protect pressure instruments with precision & reliability. Polypro body, Viton diaphragm, stainless brass Wika gauge.
Regular price
$235.95
Regular price
Sale price
$235.95
Unit price
per
Initiate Order
Polypro Gauge Isolator with Wika Stainless Brass Gauge
$235.95
Quantity: 1
Claim Your Seller Account
Polypro Gauge Isolator with Wika Stainless Brass Gauge
$235.95
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Polypro Gauge Isolator with Viton Diaphragm and stainless brass 0-160 PSI Wika Stainless Brass 2.5" Gauge is a robust and reliable solution for protecting and isolating pressure sensing instruments. Featuring a durable Polypro body and Viton diaphragm, this isolator ensures total isolation from system media while maintaining accurate pressure transmission. The low profile design eliminates dead volume, and the convoluted diaphragm allows for precise pressure containment. With easy installation and simple maintenance, this gauge isolator is a cost-effective choice for institutional and government procurement needs.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Features 0
Protects and isolates pressure sensing instruments Total isolation from system media Low profile design eliminates dead volume Convoluted diaphragm allows accurate transmission of system pressure Optimum pressure containment spherical design Low in original cost and maintenance Simple installation
Materials Of Construction 0
Body: PVC: Polyvinyl Chloride CPVC: Chlorinated Polyvinyl Chloride PP: Polypropylene homopolymer, glass & mineral reinforced Membrane: Standard: PTFE, also available in: FPM: Viton®, Fluorine elastomer EPDM: Ethylene Propylene elastomer
Scope 0
The Marquest Gauge Isolator provides two fluid chambers separated by an impermeable membrane. The upper chamber (instrument side) is normally filled with a stabilized liquid. The lower chamber receives the media under pressure. Most pressure sensing devices are compatible with 1/4" FNPT outlet. The inlet is standard 1/2" FNPT or 1/4" FNPT. Chemical resistance and purity levels are as recommended for the base materials. No metals or lubricants are used in construction, internally or externally. Custom membranes may be supplied upon request.
Specifications Inlet Connection
1/4" Female NPT
Specifications Installed Gauge
0-160 PSI, SS, Brass
Specifications List Price
235.95 USD
Specifications Materials
PP, Viton Diaphragm
