Polypro TUFF GUARD Gauge Isolator with Economy 2.5-Inch Gauge
Polypro TUFF GUARD Gauge Isolator with Economy 2.5-Inch Gauge
SKU:GAU-6e8846
Protect pressure instruments with precision using our Polypro TUFF GUARD Isolator with PTFE Diaphragm & Economy Gauge!
Regular price
$142.95
Regular price
Sale price
$142.95
Unit price
per
Initiate Order
Polypro TUFF GUARD Gauge Isolator with Economy 2.5-Inch Gauge
$142.95
Quantity: 1
Claim Your Seller Account
Polypro TUFF GUARD Gauge Isolator with Economy 2.5-Inch Gauge
$142.95
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance pressure sensing instrument protection with our Polypro TUFF GUARD Gauge Isolator featuring a PTFE diaphragm and 1/4' Female NPT Inlet Connection. This isolator ensures total media isolation, accurate pressure transmission with its convoluted diaphragm and spherical design, and easy maintenance. With a low profile design eliminating dead volume and simple installation, it meets stringent industry standards for chemical resistance and purity, making it ideal for institutional and government procurement needs.
Product Specifications
Features 0
Protects and isolates pressure sensing instruments Total isolation from system media Low profile design eliminates dead volume Convoluted diaphragm allows accurate transmission of system pressure Optimum pressure containment spherical design Low in original cost and maintenance Simple installation
Materials Of Construction 0
Body: PVC: Polyvinyl Chloride CPVC: Chlorinated Polyvinyl Chloride PP: Polypropylene homopolymer, glass & mineral reinforced Membrane: Standard: PTFE, also available in: FPM: Viton®, Fluorine elastomer EPDM: Ethylene Propylene elastomer
Scope 0
The Marquest Gauge Isolator provides two fluid chambers separated by an impermeable membrane. The upper chamber (instrument side) is normally filled with a stabilized liquid. The lower chamber receives the media under pressure. Most pressure sensing devices are compatible with 1/4" FNPT outlet. The inlet is standard 1/2" FNPT or 1/4" FNPT. Chemical resistance and purity levels are as recommended for the base materials. No metals or lubricants are used in construction, internally or externally. Custom membranes may be supplied upon request.
Specifications Inlet Connection
1/4" Female NPT
Specifications Installed Gauge
0-100 PSI, Brass, Blk Pntd Steel
Specifications List Price
142.95 USD
Specifications Materials
PP, PTFE Diaphragm
Specifications Shipping Note
We will let you know the shipping charges once we receive the order.
