The Nova 362 Series are portable analyzers that can provide a detailed analysis of flue gas composition. They have been designed to be accurate, reliable, and easy to use and maintain. Model 362 has customer-replaceable sensors, which respond quickly to the O2, CO, and NOx present in the flue gas sample. The sensor life expectancy is between 3-4 years.In operation, a built in sample pump draws in the flue gas sample through the S.S. probe, 12 ft. sample hose, condensate removal filter, secondary filter, flow meter, and then on to the three sensors. The detected O2, CO, and NO are displayed on separate LCD digital meters, which have a switchable backlight for use in dark areas. The analyzer can be operated for long periods unattended.The Nova 362 can also optionally indicate net stack temperature for doing fuel efficiency calculations (362T). The temperature sensor is built into the sampling probe. Efficiency charts for each fuel are provided.A rechargeable 'gel cell' battery provides enough power for about 16 hours of continuous operation and the analyzer can be used while it is being recharged. A red LED indicates when to recharge and a green LED verifies that it is receiving recharging power. The battery recharger is included with the analyzer. The rugged dust-tight and water resistant case is ideal for use in harsh environments.
Product Specifications
Applications 0
Analysis of oxygen (O2), carbon monoxide (CO), and oxides of nitrogen (NOx as NO). For checking combustion efficiency, air infiltration, NOx emissions, and burner & control performance of furnaces, heaters, and boilers. May be used in commercial, industrial and residential applications.
Calibration 0
Air for O2 span, CO zero and NOx zeroAnalyzed mixture of CO and NO in nitrogen for CO and NO span, and O2 zero
Features 0
Long life electrochemical sensors for each gasRugged design that is easy to operate and maintainFast warm-up and responseDigital readout meter with backlightRechargeable battery operationBuilt in sample pump, filter, flow meter, and continuous condensate removalWeatherproof (WP) cabinet with clear Lexan coverStainless steel probe with sample hoseFor use on any fuelDual CO range: 0-2000 PPM and 0-4.00% CORapid CO & NOx reading recovery on 'overdose'Pays for itself in months through fuel savings
Options 0
Recorder outputs of 0-1 V or 4-20 mAStack temperature readout (362T)Special sampling probesSample pre-coolerSuitcase (K) style cabinet availableAC power only operationNOx as NO and NO2Detachable/portable data logger
Specifications Accuracy Repeatability
<1% of O2; ± 10 PPM CO; ± 3 PPM NOx
Specifications Ambient Temperature Range
0 to 40 ºC | 32 to 105 ºF
Specifications Drift
±2% of full scale per 8 hours of continuous operation
Specifications Industry Type
Flue Gas or Emissions
Specifications Linearity
±1% of full scale of each gas measured
Specifications Method Of Detection
Customer replaceable electrochemical O2, CO and NO sensor
Specifications Output Options
4-20 mA or 0-1 VDC
Specifications Power
AC/DC Operation, 115 VAC 60 Hz for recharging (Other voltages available.)
Specifications Primary Gas To Be Measured
Carbon Monoxide (CO) | Oxides of Nitrogen (NOx) | Oxygen (O2)
Specifications Ranges Available
0-200 to 0-2000 PPM NOx (as NO); 0-1800°F (0-1000°C) net stack temperature (362T) | 0-25.0% O2; 0-2000 PPM to 0-4.00% CO (switch selectable)
Specifications Resolution
0.1% O2; 1 PPM on CO and NOx
Specifications Response Time T 90
10-12 seconds for O2; 20-30 seconds for CO and NOx
Specifications Size Weight
K Style: 10 1/2" W x 14" L x 6" H @ 13 lbs (27 x 35 x 15 cm @ 6 kg) | WP Style: 18" W x 12" L x 5 1/4" H @ 13 lbs (45 x 30 x 13 cm @ 6 kg)
Specifications Unique Applications
All Nova analyzers are built using proven technologies and techniques. If this product does not suit your application, please contact Nova. In many cases, we are able to build an analyzer specific to your needs.
