Portable Flue Gas Analyzer for Oxygen, Carbon Monoxide, Carbon Dioxide and Oxides of Nitrogen, Suitcase (K) Enclosure
Portable Flue Gas Analyzer for Oxygen, Carbon Monoxide, Carbon Dioxide and Oxides of Nitrogen, Suitcase (K) Enclosure
SKU:BYI-56d222
N/A
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Portable Flue Gas Analyzer for Oxygen, Carbon Monoxide, Carbon Dioxide and Oxides of Nitrogen, Suitcase (K) Enclosure
$49.99
Quantity: 1
Claim Your Seller Account
Portable Flue Gas Analyzer for Oxygen, Carbon Monoxide, Carbon Dioxide and Oxides of Nitrogen, Suitcase (K) Enclosure
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Nova 376 Series Portable Analyzers provide a detailed analysis of flue gas composition. They have been designed for accuracy, reliability, and ease of use and service. The sensors respond quickly to the gases of interest present in the flue gas sample. Under normal conditions of use, the O2, CO and NOx sensors each have a life expectancy of between 3 and 4 years and are customer-replaceable. The CO2 sensor should not need to be replaced.In operation, a built in sample pump draws in the flue gas sample through the S.S. probe, 12 ft. (4 m) sample hose, condensate removal filter, secondary filter and flowmeter, and then on to the four sensors. The detected O2, CO2, CO, and NOx are displayed on digital meters which have a switchable backlight for use in dark areas. The sensors do not require special SO2 scrubbing chemicals as do some types of analyzers.The Nova 376T version also indicates stack temperature for doing fuel efficiency calculations. The temperature sensor is built into the sampling probe. Efficiency charts for each fuel are provided. A rechargeable 'gel cell' battery provides enough power for about 16 hours of continuous operation and the analyzer can be used while it is being recharged. A red LED tells when to recharge and a green LED verifies that it is receiving recharging power.
Product Specifications
Applications 0
Analysis of oxygen (O2), carbon monoxide (CO), carbon dioxide (CO2) and oxides of nitrogen (NOx as NO). For checking the combustion efficiency and burner & control performance of furnaces, heaters, and boilers. May be used in commercial, industrial, and residential settings.
Calibration 0
Air for O2 span and CO/CO2 zeroAnalyzed gas mixtures of CO2, CO, and NOx in nitrogen for span
Features 0
Rugged design that is easy to operate and maintainFast warm up and responseCO2 actually measured by infra-red detector, not calculatedDual CO range : 0-2000 ppm & 0-4.00%Rapid reading recovery after CO or NO 'overdose'Digital readout meters with backlightRechargeable battery operationBuilt in sample pump, filter and flow meterActive condensate removalWeatherproof (WP) cabinet with clear Lexan coverStainless steel probe with sample hoseUse on any fuel
Options 0
Outputs of 0-1 V or 4-20 mA (can be isolated)Stack temperature readout (376T)Special sampling probesSuitcase (K) style cabinet availableAC power only operationGas alarms with LEDDetachable/portable data logger
Specifications Accuracy Repeatability
Within ±0.1% O2 and CO2; ±10 PPM CO and NO
Specifications Ambient Temperature Range
0 to 40 ºC | 32 to 105 ºF
Specifications Drift
2% full scale per 8 hours of continuous operation
Specifications Hazardous Area Rating Options
General Purpose, Non-Hazardous
Specifications Linearity
±1.0% of full scale for each gas measured
Specifications Method Of Detection
Customer replaceable electrochemical O2, CO and NO sensors | Solid state infrared detector for CO2
Specifications Output Options
0-1 VDC | 4-20 mA
Specifications Power
AC/DC Operation, 115 VAC, 60 Hz for recharging
Specifications Ranges Available
0-1800°F (0-1000°C) stack temperature | 0-20.0% CO2 | 0-200 to 0-2000 PPM NOx (as NO) ranges available | 0-2000 PPM and 0-4.00% CO - Switch selectable | 0-25.0% O2
Specifications Response Time T 90
10-15 seconds for O2; 20-30 seconds for CO, NO, and CO2
Specifications Size Weight
18" L x 7" H x 12" D @ 15 lbs (45.7 x 30.5 x 17.8 cm @ 6.8 kg)
Unique Applications 0
The 376 Series should not be used for detecting these gases in ambient atmospheres for personnel safety purposes. All Nova analyzers are built using proven technologies and techniques. If this product does not suit your application, please contact Nova. In many cases, we are able to build an analyzer specific to your needs.
