Portable Multi-Gas Ambient Air Analyzer
Portable Multi-Gas Ambient Air Analyzer
SKU:MUL-71ec9b
N/A
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Portable Multi-Gas Ambient Air Analyzer
$49.99
Quantity: 1
Claim Your Seller Account
Portable Multi-Gas Ambient Air Analyzer
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
For ambient air or confined space monitoring for up to any four choices of O2, CO2, NO, NO2, CO, LEL combustibles, temperature, and % RH. Single gas versions are also available for H2S, SO2, Cl2, HCL & NH3.
Product Specifications
Applications 0
For ambient air or confined space monitoring for up to any four choices of O2, CO2, SO2, NO, NO2, H2, CO, Cl2, NH3, H2S, LEL combustibles, temperature, and % RH.
Calibration 0
Nitrogen (N2) for zero Analyzed gas cylinders for span
Features 0
Rugged design that is easy to operate and maintain Fast warm-up and response Separate electrochemical sensor for O2, CO, SO2, NO, NO2, H2, CL2, NH3, and H2S Sensitive infrared detector for CO2 Catalytic sensor for combustibles Capacitive ceramic sensor for % RH Digital readout with backlighting for each gas Built in sampling pump, flow meter, filter and 12 ft. sampling hose Rechargeable battery Rugged suitcase (K) style case
Options 0
Audible and visual alarms Built in printer
Specifications Accuracy Repeatability
±2% of full scale
Specifications Alarms
Audible and visual alarms are optionally available as well as low battery and low flow
Specifications Ambient Temperature Range
4 to 49 ºC | 40 to 120 ºF
Specifications Drift
Less than 1% of full scale or 1 PPM per 8 hours, whichever is greater, with constant ambient temperature
Specifications Gases Measured
0) NH3 - 0-20 PPM | 1) O2 - 0-25.0% | 2) CO - 0-200 PPM | 3) CO2 - 0-5000 PPM | 4) LEL Combustibles (not avail. for 501 Series) | 5) H2S - 0-20 PPM | 6) SO2 - 0-50 PPM | 7) NO - 0-100 PPM | 8) NO2 - 0-20 PPM | 9) Cl2 - 0-20 PPM
Specifications Industry Type
Indoor Air Quality | Personnel Safety | Steel Making
Specifications Linearity
±2% of full scale or 1 PPM, whichever is greater
Specifications Method Of Detection
O2, CO, SO2, NO, NO2, H2, CL2, NH3 and H2S by electrochemical sensor, % RH by dielectric ceramic sensor, CO2 by infrared sensor, combustibles by catalytic sensor
Specifications Models Configuration Guidelines
Standard system comes with 'K' series suitcase-style enclosure, built-in sampling pump, flow meter, pre-filter, liquid block, 12 ft (3.6 m) sample hose, rechargeable battery, and recharger.
Specifications Output Options
0-1 VDC | 4-20 mA
Specifications Power
115 VAC, 60 Hz for recharging | 220 VAC, 50 Hz
Specifications Ranges Available
0-100 PPM NO | 0-100% RH | 0-20 PPM H2S | 0-20 PPM NH3 | 0-20.0 PPM CL2 | 0-20.0 PPM NO2 | 0-200 PPM CO | 0-200 PPM H2 | 0-25.0% O2 | 0-50°C Temp. | 0-50.0 PPM SO2 | 0-5000 PPM CO2
Specifications Resolution
0.1% on % gas, 1 PPM on PPM gas
Specifications Response Time T 90
Varies with individual sensor but generally under 2 minutes for full reading
Specifications Size Weight
15" W x 7" H x 12" D @ 14 lbs. (374 x 175 x 305 mm @ 6.4 kg)
Specifications Unique Applications
Warm up time is approximately two minutes however NO and NH3 may take up to 2 hours for full stability. The operating humidity range for this series of analyzers is 0-90% RH non-condensing. All Nova analyzers are built using proven technologies and techniques. If this product does not suit your application, please contact Nova. In many cases, we are able to build an analyzer specific to your needs.
