PPS PolyphenyleneSulfide Sheet
PPS PolyphenyleneSulfide Sheet
SKU:SHA-b78e61
Explore the PPS PolyphenyleneSulfide Sheet - High chemical resistance, precision machining, and flame-retardant properties. Ideal for critical components.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
PPS PolyphenyleneSulfide Sheet
$99.99
Quantity: 1
Claim Your Seller Account
PPS PolyphenyleneSulfide Sheet
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PPS PolyphenyleneSulfide Sheet offers exceptional chemical resistance, with superb performance against solvents, steam, bases, fuels, and acids. Engineered for precision machining, it boasts low moisture absorption, minimal thermal expansion, and superior electrical properties. This inherently flame-retardant sheet is ideal for high-tolerance components, exhibiting high strength, excellent dimensional stability, and wear resistance. With compliance to ASTM D 6358, and a flammability rating of V0 (UL 94), this PPS sheet is a reliable choice for diverse applications.
Product Specifications
Advantages 0
High Strength.Excellent chemical & hydrolysis resistance.Very good dimensional stability.Excellent wear & frictional behavior.Inherent low flammability. Excellent alternative to PEEK at lower temperatures.Good electrical insulating & dielectric properties.Essentially zero moisture absorption.
Applications 0
Pump housings.High pressure liquid Chromatography components.Chip nests.Retaining rings.Wafer Carriers.Laboratory & Analytical Equipment.
Specifications Astm Shape Spec
ASTM D 6358
Specifications Availability
stock
Specifications Coefficient Of Friction Dynamic
.40
Specifications Color
Off-white
Specifications Dielectric Strength
540 V/mil
Specifications Flammability Rating Ul 94
V0 (.125")
Specifications Flexural Modulus
575000 psi
Specifications Flexural Strength
21000 psi
Specifications Hardness Durometer Shore D
85
Specifications Heat Deflection Temperature 264 Psi
250 ºF
Specifications Impact Strength Notched
.60 ft·lb/in
Specifications Material
PPS
Specifications Maximum Operating Temperature
425 ºF
Specifications Minimum Order
1
Specifications Optional Sheet Size
12"x48"⢠24"x48"
Specifications Sheet Size
12 x 12 in
Specifications Specific Gravity
1.35
Specifications Tensile Strength
13500 psi
Specifications Thickness
1.00 in
Specifications Tolerance
+only in
Specifications Weight
1.76 lb/ft²
