PPS Sheet - Polyphenylene Sulfide Sheet
PPS Sheet - Polyphenylene Sulfide Sheet
SKU:SHA-da7acf
Explore our high-strength PPS Sheet for precise machining with exceptional chemical resistance. Compliant with ASTM standards and V0 flammability rating.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
PPS Sheet - Polyphenylene Sulfide Sheet
$49.99
Quantity: 1
Claim Your Seller Account
PPS Sheet - Polyphenylene Sulfide Sheet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our PPS Sheet is a high-performance engineering plastic known for its exceptional chemical resistance and dimensional stability. With a wide range of applications from pump housings to laboratory equipment, this off-white sheet offers minimal moisture absorption, low thermal expansion, and excellent electrical properties. Compliant with ASTM D 6358 and bearing a V0 flammability rating, this PPS Sheet is an ideal choice for precision machined components in diverse industries.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Advantages 0
High Strength.Excellent chemical & hydrolysis resistance.Very good dimensional stability.Excellent wear & frictional behavior.Inherent low flammability. Excellent alternative to PEEK at lower temperatures.Good electrical insulating & dielectric properties.Essentially zero moisture absorption.
Applications 0
Pump housings.High pressure liquid Chromatography components.Chip nests.Retaining rings.Wafer Carriers.Laboratory & Analytical Equipment.
Specifications Astm Shape Spec
ASTM D 6358
Specifications Availability
3-5 days
Specifications Coefficient Of Friction Dynamic
.40
Specifications Color
Off-white
Specifications Dielectric Strength
540 V/mil
Specifications Flammability Rating Ul 94
V0 (.125")
Specifications Flexural Modulus
575000 psi
Specifications Flexural Strength
21000 psi
Specifications Hardness Durometer Shore D
85
Specifications Heat Deflection Temperature 264 Psi
250 ºF
Specifications Impact Strength Notched
.60 ft·lb/in
Specifications Material
PPS
Specifications Maximum Operating Temperature
425 ºF
Specifications Minimum Order
1
Specifications Optional Sheet Size
12"x48"⢠24"x48"
Specifications Sheet Size
12 x 12 in
Specifications Specific Gravity
1.35
Specifications Tensile Strength
13500 psi
Specifications Thickness
0.875 in
Specifications Tolerance
+only in
Specifications Weight
1.76 lb/ft²
