Precision Fixed Flow Ball Controls - NPT Nipple

Name: Precision Fixed Flow Ball Controls - NPT Nipple
Brand: O'Keefe Controls Co.
SKU: FLO-44bfd7
Price: 49.99 USD
Availability: OutOfStock

SKU:FLO-44bfd7

Premium all-metal Fixed Flow Ball Controls for precise liquid and gas regulation

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Precision Fixed Flow Ball Controls - NPT Nipple are expertly crafted with all metal construction for long-lasting, tamperproof operation. Featuring a choice of cracking pressure, these controls ensure high-pressure capacity and precise flow regulation in liquids and gases. With dimensions including Orifice Diameter of 0.021 in and Total Length of 1.4 in, these controls meet stringent performance standards, making them ideal for a range of applications.

Product Specifications

Dimensions Orifice Diameter

0.021 in

Dimensions Total Length

1.4 in

Dimensions Width Across Flats Hex

9/16 in

Features Features

All metal construction Long life operation Choice of cracking pressure Tamperproof Orifice High Pressure Capacity

Flow Data Air Flow At 100 Psig

346 to 662 ftÂ³/h

Flow Data Water Flow At 100 Psig

0.8 to 1.6 gpm

Specifications Assembly Forward Cv

0.091

Specifications Ball Material

304 SS

Specifications Check Valve Cv

0.081

Specifications Connection A

1/8" NPT Male

Specifications Connection B

1/8" NPT Male

Specifications Cracking Pressure

2 psig

Specifications Cv Ratio Forward Cv Return Cv

9.44

Specifications Material

303 SS

Specifications Maximum Operating Pressure Gauge

200 psig

Specifications Nominal Orifice Size

Specifications Orifice Cv Return

0.0096

Specifications Screened

None
