Precision Fixed Flow Control - Ball Type NPT Nipple

Name: Precision Fixed Flow Control - Ball Type NPT Nipple
Brand: O'Keefe Controls Co.
SKU: FLO-5b96ab
Price: 39.99 USD
Availability: OutOfStock

SKU:FLO-5b96ab

High-quality Precision Fixed Flow Control for accurate liquid and gas regulation.

$39.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Precision Fixed Flow Control - Ball Type NPT Nipple offers a reliable solution for precise flow regulation in both liquid and gas applications. This product features an all-metal construction with brass material and a 304 SS ball for durability and high-pressure capacity. With a tamperproof orifice and a choice of cracking pressure, this fixed flow control ensures long-lasting and efficient operation. Suitable for various industries, this product meets rigorous quality standards, making it a dependable choice for institutional and government procurement.

Product Specifications

Dimensions Orifice Diameter

0.02 in

Dimensions Total Length

1.91 in

Dimensions Width Across Flats Hex

11/16 in

Features Features

All metal construction Long life operation Choice of cracking pressure Tamperproof Orifice High Pressure Capacity

Flow Data Air Flow At 100 Psig

809 to 1650 ftÂ³/h

Flow Data Water Flow At 100 Psig

1.9 to 3.9 gpm

Specifications Assembly Forward Cv

0.200

Specifications Ball Material

304 SS

Specifications Check Valve Cv

0.191

Specifications Connection A

1/4" NPT Male

Specifications Connection B

1/4" NPT Female

Specifications Cracking Pressure

2 psig

Specifications Cv Ratio Forward Cv Return Cv

22.70

Specifications Material

Brass

Specifications Maximum Operating Pressure Gauge

200 psig

Specifications Nominal Orifice Size

Specifications Orifice Cv Return

0.0088

Specifications Screened

None

Precision Fixed Flow Control - Ball Type NPT Nipple
