Precision Fixed Flow Control Valve - Brass Ball Type NPT Nipple

Name: Precision Fixed Flow Control Valve - Brass Ball Type NPT Nipple
Brand: O'Keefe Controls Co.
SKU: FLO-effb0b
Price: 79.99 USD
Availability: OutOfStock

SKU:FLO-effb0b

Reliable Precision Flow Control Valve for liquids and gases with tamperproof orifice and high-pressure capacity.

$79.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Precision Fixed Flow Control Valve with Ball Type NPT Nipple offers reliable and precise flow control for both liquids and gases. Featuring an orifice diameter of 0.04 in and a high-pressure capacity, this valve ensures optimal performance. With an all-metal construction, tamperproof orifice, and a choice of cracking pressure, it provides long-lasting operation. This valve meets stringent industry standards for durability and performance, making it ideal for institutional and government procurement needs.

Product Specifications

Dimensions Orifice Diameter

0.04 in

Dimensions Total Length

1.4 in

Dimensions Width Across Flats Hex

9/16 in

Features Features

All metal construction Long life operation Choice of cracking pressure Tamperproof Orifice High Pressure Capacity

Flow Data Air Flow At 100 Psig

346 to 662 ftÂ³/h

Flow Data Water Flow At 100 Psig

0.8 to 1.6 gpm

Specifications Additional Wetted Material

Loctite 609 / 680

Specifications Assembly Forward Cv

0.117

Specifications Ball Material

304 SS

Specifications Check Valve Cv

0.081

Specifications Connection A

1/8" NPT Male

Specifications Connection B

1/8" NPT Male

Specifications Cracking Pressure

2 psig

Specifications Cv Ratio Forward Cv Return Cv

3.25

Specifications Material

Brass

Specifications Maximum Operating Pressure Gauge

2000 psig

Specifications Nominal Orifice Size

Specifications Orifice Cv Return

0.036

Specifications Screened

None

Specifications Seal Material

Loctite 609, 680
