Precision Fixed Flow Controls - Ball Type NPT Nipple
Precision Fixed Flow Controls - Ball Type NPT Nipple
SKU:FLO-49b526
Premium fixed flow controls for precise flow management in liquids and gases. Durable construction, high pressure capacity.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Precision Fixed Flow Controls - Ball Type NPT Nipple
$45.99
Quantity: 1
Claim Your Seller Account
Precision Fixed Flow Controls - Ball Type NPT Nipple
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Precision Fixed Flow Controls - Ball Type NPT Nipple is a premium solution for precise flow management. Featuring a parallel arrangement of a ball check valve and a precision orifice, this component ensures free flow in one direction and accurately metered flow in the other. Crafted from high-quality 303 SS and 304 SS materials, with seals made of Loctite 609/680, this product guarantees durability and reliability in diverse operational environments. With a wide range of technical specifications, including a high maximum operating pressure of 2000 psig and precise flow data for both air and water, these flow controls offer exceptional performance. The all-metal construction, choice of cracking pressure, tamperproof orifice, and high-pressure capacity make it ideal for demanding applications.
Product Specifications
Dimensions Orifice Diameter
0.037 in
Dimensions Total Length
1.4 in
Dimensions Width Across Flats Hex
9/16 in
Features Features
All metal construction Long life operation Choice of cracking pressure Tamperproof Orifice High Pressure Capacity
Flow Data Air Flow At 100 Psig
346 to 662 ft³/h
Flow Data Water Flow At 100 Psig
0.8 to 1.6 gpm
Specifications Additional Wetted Material
Loctite 609 / 680
Specifications Assembly Forward Cv
0.112
Specifications Ball Material
304 SS
Specifications Check Valve Cv
0.081
Specifications Connection A
1/8" NPT Male
Specifications Connection B
1/8" NPT Male
Specifications Cracking Pressure
0 psig
Specifications Cv Ratio Forward Cv Return Cv
3.61
Specifications Material
303 SS
Specifications Maximum Operating Pressure Gauge
2000 psig
Specifications Nominal Orifice Size
37
Specifications Orifice Cv Return
0.031
Specifications Screened
None
Specifications Seal Material
Loctite 609, 680
