Precision Machining Gantry High Speed Mill
Precision Machining Gantry High Speed Mill
SKU:HIG-375bb8
Enhance precision and productivity with the Precision Machining Gantry High Speed Mill. Delivering exceptional speed and accuracy for industrial applications.
Regular price
$28,999.99
Regular price
Sale price
$28,999.99
Unit price
per
Initiate Order
Precision Machining Gantry High Speed Mill
$28,999.99
Quantity: 1
Claim Your Seller Account
Precision Machining Gantry High Speed Mill
$28,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Precision Machining Gantry High Speed Mill offers unparalleled precision and performance for industrial applications. With a maximum spindle speed of 30,000 rpm and a robust spindle motor power of 17 kW, this high-speed mill delivers exceptional accuracy and efficiency. The working table size of 850 x 600 mm can accommodate a maximum load of 800 kg, making it ideal for high-capacity machining tasks. Equipped with AC servo motors and advanced automation features, this mill ensures optimal productivity and seamless integration.
Product Specifications
Features 0
High Accuracy: Economical Position High Productivity: Application DrivenHigh Efficiency: Utmost Performance Integration, Solution and Automation
Note 0
G means equipped graphite cutting unit.T means equipped ATC unit.
Specifications Distance From Table Surface To Spindle Nose
160 to 560 mm
Specifications Maximum Load Of Table
800 kg
Specifications Maximum Spindle Speed
30000 rpm
Specifications Maximum Total Power Consumption
30 kV·A
Specifications Net Weight
7500 kg
Specifications Rapid Traverse X Y Z
30 m/min
Specifications Spindle Motor Power S1
15 kW
Specifications Spindle Motor Power S6
17 kW
Specifications Spindle Taper
HSK E50
Specifications Travel X X Y X Z
800 x 600 x 400 mm
Specifications T Slot
16 x 5 x 100 mm
Specifications Working Table Size
850 x 600 mm
Specifications Work Feed
10 m/min
Specifications X Y Z Axis Servo Motor
AC servo motor
