Enhance fluid control with our Precision Metal Orifice Push-On Tube Adapters. Made of durable brass/plastic with Buna-N seals, these adapters ensure a secure fit for precise airflow regulation. With an orifice diameter of 0.028 inches and maximum operating pressure of 140 psig, they deliver accurate flow rates for various applications. Ideal for industrial and government settings, these adapters meet strict procurement standards and ensure reliable performance.
Product Specifications
Dimensions Orifice Diameter
0.028 in
Dimensions Total Length
0.66 in
Dimensions Width Across Flats Hex
9/32 in
Flow Data Air Flow At Pressure Standard Cu Ft Per Hour Scfh
1 psig: 4.68 | 5 psig: 10.5 | 10 psig: 15.2 | 15 psig: 18.6 | 20 psig: 21.8 | 25 psig: 24.8 | 30 psig: 28.0 | 40 psig: 34.1 | 50 psig: 40.3 | 60 psig: 46.4 | 70 psig: 52.5 | 80 psig: 58.7 | 90 psig: 65.0 | 100 psig: 71.4
Flow Data Air Flow At Pressure Standard Liters Per Minute Slpm
1 psig (6.9 kPag): 2.21 | 5 psig (34.5 kPag): 4.94 | 10 psig (69.0 kPag): 7.18 | 15 psig (103.4 kPag): 8.78 | 20 psig (137.9 kPag): 10.3 | 25 psig (172.4 kPag): 11.7 | 30 psig (206.9 kPag): 13.2 | 40 psig (275.8 kPag): 16.1 | 50 psig (344.8 kPag): 19.0 | 60 psig (413.7 kPag): 21.9 | 70 psig (482.7 kPag): 24.8 | 80 psig (551.6 kPag): 27.7 | 90 psig (620.6 kPag): 30.7 | 100 psig (689.5 kPag): 33.7
Flow Data Air Flow At Vacuum Choked Flow Standard Cu Ft Per Hour
15 In. Hg.: 8.90 | 20 In. Hg.: 8.9 | 30 In. Hg.: 8.90
Flow Data Air Flow At Vacuum Choked Flow Standard Liters Per Min
15 In. Hg. (381 Mm. Hg.): 4.20 | 20 In. Hg. (508 Mm. Hg.): 4.20 | 30 In. Hg. (762 Mm. Hg.): 4.20
Flow Data Air Flow At Vacuum Standard Cu Ft Per Hour Scfh
5 In. Hg.: 6.7 | 10 In. Hg.: 8.48
Flow Data Air Flow At Vacuum Standard Liters Per Minute Slpm
5 In. Hg. (127 Mm. Hg.): 3.16 | 10 In. Hg. (254 Mm. Hg.): 4.00
Flow Data Flow Data Status
Generic
Flow Data Water Flow Gallonsminute Gpm
1 psig: 0.018 | 2 psig: 0.025 | 3 psig: 0.031 | 4 psig: 0.036 | 5 psig: 0.040 | 6 psig: 0.044 | 7 psig: 0.048 | 8 psig: 0.051 | 9 psig: 0.054 | 10 psig: 0.057 | 15 psig: 0.070 | 20 psig: 0.080 | 30 psig: 0.099 | 40 psig: 0.114 | 50 psig: 0.127 | 60 psig: 0.139 | 70 psig: 0.151 | 80 psig: 0.161 | 90 psig: 0.171 | 100 psig: 0.180
Flow Data Water Flow Litersminute Lpm
1 psig (6.9 kPag): 0.068 | 2 psig (13.8 kPag): 0.096 | 3 psig (20.7 kPag): 0.118 | 4 psig (27.6 kPag): 0.136 | 5 psig (34.5 kPag): 0.152 | 6 psig (41.4 kPag): 0.152 | 7 psig (48.3 kPag): 0.180 | 8 psig (55.2 kPag): 0.193 | 9 psig (62.1 kPag): 0.204 | 10 psig (69 kPag): 0.215 | 15 psig (103.4 kPag): 0.264 | 20 psig (137.9 kPag): 0.305 | 30 psig (206.9 kPag): 0.373 | 40 psig (275.8 kPag): 0.431 | 50 psig (344.8 kPag): 0.482 | 60 psig (413.7 kPag): 0.528 | 70 psig (482.7 kPag): 0.570 | 80 psig (551.6 kPag): 0.609 | 90 psig (620.6 kPag): 0.646 | 100 psig (689.5 kPag): 0.681
Specifications Connection A
10-32 UNF Male
Specifications Connection B
1/8" OD Tube Push-Lock
Specifications Cv
0.018
Specifications Material
Brass/Plastic
Specifications Maximum Operating Pressure
140 psig
Specifications Nominal Orifice Size
28
Specifications Screened
None
Specifications Seal Material
Buna-N
