The Precision Metal Orifice Push-On Tube Adapters are engineered with Brass/Plastic material and Buna-N seal for optimal performance. With a Nominal Orifice Size of 42 and a CV of 0.039, these adapters can withstand a Maximum Operating Pressure of 140 psig. The 1/4" NPT Male Connection A and 5/32" OD Tube Push-Lock Connection B ensure secure fittings. Ideal for precise flow control, these adapters offer accurate Air and Water flow rates, meeting strict industry standards for reliability and efficiency.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions Orifice Diameter
0.042 in
Dimensions Total Length
0.77 in
Dimensions Width Across Flats Hex
5/8 in
Flow Data Air Flow At Pressure Standard Cu Ft Per Hour Scfh
1 psig: 10.60 | 5 psig: 23.9 | 10 psig: 33.1 | 15 psig: 40.5 | 20 psig: 47.7 | 25 psig: 54.9 | 30 psig: 62.3 | 40 psig: 76.9 | 50 psig: 91.7 | 60 psig: 107 | 70 psig: 122 | 80 psig: 137 | 90 psig: 151 | 100 psig: 167
Flow Data Air Flow At Pressure Standard Liters Per Minute Slpm
1 psig (6.9 kPag): 4.99 | 5 psig (34.5 kPag): 11.3 | 10 psig (69.0 kPag): 15.6 | 15 psig (103.4 kPag): 19.1 | 20 psig (137.9 kPag): 22.5 | 25 psig (172.4 kPag): 25.9 | 30 psig (206.9 kPag): 29.4 | 40 psig (275.8 kPag): 36.3 | 50 psig (344.8 kPag): 43.3 | 60 psig (413.7 kPag): 50.3 | 70 psig (482.7 kPag): 57.4 | 80 psig (551.6 kPag): 64.5 | 90 psig (620.6 kPag): 71.5 | 100 psig (689.5 kPag): 78.6
Flow Data Air Flow At Vacuum Choked Flow Standard Cu Ft Per Hour
15 In. Hg.: 20.0 | 20 In. Hg.: 20.0 | 30 In. Hg.: 20.0
Flow Data Air Flow At Vacuum Choked Flow Standard Liters Per Min
15 In. Hg. (381 Mm. Hg.): 9.46 | 20 In. Hg. (508 Mm. Hg.): 9.46 | 30 In. Hg. (762 Mm. Hg.): 9.46
Flow Data Air Flow At Vacuum Standard Cu Ft Per Hour Scfh
5 In. Hg.: 15.4 | 10 In. Hg.: 19.2
Flow Data Air Flow At Vacuum Standard Liters Per Minute Slpm
5 In. Hg. (127 Mm. Hg.): 7.29 | 10 In. Hg. (254 Mm. Hg.): 9.08
Flow Data Flow Data Status
Generic
Flow Data Water Flow Gallonsminute Gpm
1 psig: 0.039 | 2 psig: 0.055 | 3 psig: 0.068 | 4 psig: 0.078 | 5 psig: 0.087 | 6 psig: 0.096 | 7 psig: 0.103 | 8 psig: 0.110 | 9 psig: 0.117 | 10 psig: 0.123 | 15 psig: 0.151 | 20 psig: 0.174 | 30 psig: 0.214 | 40 psig: 0.247 | 50 psig: 0.276 | 60 psig: 0.302 | 70 psig: 0.326 | 80 psig: 0.349 | 90 psig: 0.370 | 100 psig: 0.390
Flow Data Water Flow Litersminute Lpm
1 psig (6.9 kPag): 0.148 | 2 psig (13.8 kPag): 0.209 | 3 psig (20.7 kPag): 0.256 | 4 psig (27.6 kPag): 0.295 | 5 psig (34.5 kPag): 0.330 | 6 psig (41.4 kPag): 0.362 | 7 psig (48.3 kPag): 0.391 | 8 psig (55.2 kPag): 0.418 | 9 psig (62.1 kPag): 0.443 | 10 psig (69 kPag): 0.467 | 15 psig (103.4 kPag): 0.572 | 20 psig (137.9 kPag): 0.660 | 30 psig (206.9 kPag): 0.809 | 40 psig (275.8 kPag): 0.934 | 50 psig (344.8 kPag): 1.044 | 60 psig (413.7 kPag): 1.144 | 70 psig (482.7 kPag): 1.235 | 80 psig (551.6 kPag): 1.320 | 90 psig (620.6 kPag): 1.401 | 100 psig (689.5 kPag): 1.476
Specifications Connection A
1/4" NPT Male
Specifications Connection B
5/32" OD Tube Push-Lock
Specifications Cv
0.039
Specifications Material
Brass/Plastic
Specifications Maximum Operating Pressure
140 psig
Specifications Nominal Orifice Size
42
Specifications Screened
None
Specifications Seal Material
Buna-N
