Precision Metal Pressure Snubber - NPT Pipe Adapter

Name: Precision Metal Pressure Snubber - NPT Pipe Adapter
Brand: O'Keefe Controls Co.
SKU: PRE-fcc615
Price: 29.99 USD
Availability: OutOfStock

SKU:PRE-fcc615

Efficiently control pressure fluctuations with the Precision Metal Pressure Snubber NPT Pipe Adapter. Ideal for Pressure Gauges, Valves, and Actuators.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Precision Metal Pressure Snubber NPT Pipe Adapter is a vital in-line element designed to minimize rapid pressure fluctuations in a variety of components, including Pressure Gauges, Measuring Instruments, and Hydraulic/Pneumatic Valves. Crafted from durable Brass with an Orifice Diameter of 0.008 inches, it ensures efficient flow control and shock reduction. With a Maximum Operating Pressure of 2000 psig, this adapter guarantees reliable performance in demanding industrial environments. From controlling fluid delivery to maintaining system stability, this precision accessory is an indispensable component for fluid power systems.

Product Specifications

Application 0

Pressure snubbers are used as in-line elements to reduce rapid pressure fluctuations in the following types of components: Pressure Gages Pressure Measuring Instruments Air Piloted Valves Hydraulic Piloted Valves They can also be used to control the flow rate of fluid delivered to: Air Cylinders Hydraulic Cylinders Fluid Actuators

Dimensions Orifice Diameter

0.008 in

Dimensions Total Length

0.880 in

Dimensions Width Across Flats Hex

9/16 in

Specifications Connection A

1/8" NPT Male

Specifications Connection B

1/8" NPT Female

Specifications Cv

0.0015

Specifications Material

Brass

Specifications Maximum Operating Pressure

2000 psig

Specifications Screened

None

Precision Metal Pressure Snubber - NPT Pipe Adapter
