Precision Metal Pressure Snubber NPT Pipe Adapter
Precision Metal Pressure Snubber NPT Pipe Adapter
SKU:PRE-24c714
Enhance precision and stability with our Precision Metal Pressure Snubber NPT Adapter. Control fluid flow effectively with its optimized design.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Precision Metal Pressure Snubber NPT Pipe Adapter
$45.99
Quantity: 1
Claim Your Seller Account
Precision Metal Pressure Snubber NPT Pipe Adapter
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Precision Metal Pressure Snubber NPT Pipe Adapter is a vital inline component designed to effectively mitigate rapid pressure changes in various pressure instruments and control systems. Crafted from durable 303 SS material, this adapter boasts an optimized orifice diameter of 0.015 inches to ensure precise fluid flow control. With a maximum operating pressure of 4000 psig, it offers reliable performance in demanding environments. Ideal for pressure gauges, measuring instruments, and hydraulic valves, this adapter enhances operational stability and accuracy.
Product Specifications
Application 0
Pressure snubbers are used as in-line elements to reduce rapid pressure fluctuations in the following types of components: Pressure Gages Pressure Measuring Instruments Air Piloted Valves Hydraulic Piloted Valves They can also be used to control the flow rate of fluid delivered to: Air Cylinders Hydraulic Cylinders Fluid Actuators
Dimensions Orifice Diameter
0.015 in
Dimensions Total Length
1.25 in
Dimensions Width Across Flats Hex
3/4 in
Specifications Connection A
1/4" NPT Male
Specifications Connection B
1/4" NPT Female
Specifications Cv
0.005
Specifications Material
303 SS
Specifications Maximum Operating Pressure
4000 psig
Specifications Screened
None
