Precision Motorized Linear Translation Stage L-509
Precision Motorized Linear Translation Stage L-509
SKU:MOT-4c5bb1
Compact design, high load capacity, precise motion control with optional linear encoders, ideal for autofocusing, laser cutting, and research applications.
Regular price
$899.99
Regular price
Sale price
$899.99
Unit price
per
Initiate Order
Precision Motorized Linear Translation Stage L-509
$899.99
Quantity: 1
Claim Your Seller Account
Precision Motorized Linear Translation Stage L-509
$899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Precision Motorized Linear Translation Stage L-509 is a versatile solution designed for precision motion control in demanding applications. With a compact design and a load capacity of up to 10 kg, this stage features optional Direct-measuring linear encoders for enhanced accuracy. The ActiveDrive system provides a choice of motor options including DC, BLDC, DC gear, and stepper motors, ensuring optimal performance. Equipped with crossed roller guides with an anti-creep system and a precision ball screw with 1 mm pitch, this stage delivers high travel accuracy. The stress-relieved aluminum base offers stability, while noncontact optical limit switches and reference switch ensure reliable operation. Suitable for a wide range of fields including autofocusing, laser cutting, research, biotechnology, and automation, this stage offers highly accurate position measuring with its incremental linear encoder technology.
Product Specifications
More Information Specifications Cad Drawings Manuals Etc Click L
Specifications, CAD / Drawings, Manuals, Videos
