Precision Pressure Snubber - NPT Brass Adapter

Name: Precision Pressure Snubber - NPT Brass Adapter
Brand: O'Keefe Controls Co.
SKU: PRE-e2c884
Price: 24.99 USD
Availability: OutOfStock

SKU:PRE-e2c884

Efficiently reduce pressure fluctuations with this Precision NPT Brass Adapter. Ideal for instruments & controls. Meets institutional standards.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Precision Pressure Snubber is a vital component designed to reduce rapid pressure fluctuations in various instruments and controls. Featuring a .008" orifice diameter and brass material construction, this NPT Brass Adapter ensures efficient dampening of shock and pressure effects while maintaining a maximum operating pressure of 2000 psig. Ideal for pressure gages, measuring instruments, and fluid delivery systems, this product offers exceptional reliability and longevity. With orifice sizes ranging from .004" to .020" and compliance with Federal/DoD procurement standards and industry-specific certifications, the Precision Pressure Snubber meets the stringent requirements of institutional buyers.

Product Specifications

Application 0

Pressure snubbers are used as in-line elements to reduce rapid pressure fluctuations in the following types of components: Pressure Gages Pressure Measuring Instruments Air Piloted Valves Hydraulic Piloted Valves They can also be used to control the flow rate of fluid delivered to: Air Cylinders Hydraulic Cylinders Fluid Actuators

Dimensions Orifice Diameter

0.008 in

Dimensions Total Length

1.520 in

Dimensions Width Across Flats Hex

7/8 in

Specifications Connection A

3/8" NPT Male

Specifications Connection B

3/8" NPT Female

Specifications Cv

0.0015

Specifications Material

Brass

Specifications Maximum Operating Pressure

2000 psig

Specifications Screened

None
