The PrecisionFlow Ball NPT Nipple is a high-performance fixed flow control solution designed for precise metering and control of liquids and gases. It features an orifice diameter of 0.013 in and a maximum operating pressure of 2000 psig, making it ideal for a wide range of applications. Constructed with brass material and 304 SS ball, this fixed flow control ensures durability, reliability, and tamperproof operation. With features like a choice of cracking pressure and high-pressure capacity, this product provides long-lasting performance in demanding environments. It complies with Federal/DoD procurement standards, GSA requirements, FAR compliance factors, and industry-specific certifications.
Product Specifications
Dimensions Orifice Diameter
0.013 in
Dimensions Total Length
1.4 in
Dimensions Width Across Flats Hex
9/16 in
Features Features
All metal construction Long life operation Choice of cracking pressure Tamperproof Orifice High Pressure Capacity
Flow Data Air Flow At 100 Psig
346 to 662 ft³/h
Flow Data Water Flow At 100 Psig
0.8 to 1.6 gpm
Specifications Additional Wetted Material
Loctite 609 / 680
Specifications Assembly Forward Cv
0.085
Specifications Ball Material
304 SS
Specifications Check Valve Cv
0.081
Specifications Connection A
1/8" NPT Male
Specifications Connection B
1/8" NPT Male
Specifications Cracking Pressure
0 psig
Specifications Cv Ratio Forward Cv Return Cv
22.32
Specifications Material
Brass
Specifications Maximum Operating Pressure Gauge
2000 psig
Specifications Nominal Orifice Size
13
Specifications Orifice Cv Return
0.0038
Specifications Screened
None
Specifications Seal Material
Loctite 609, 680
