Premium Ball Type Check Valves - NPT Connection, Brass & Stainless Steel
Premium Ball Type Check Valves - NPT Connection, Brass & Stainless Steel
SKU:CHE-61137b
High-quality Ball Type Check Valves for precise and reliable flow control in industrial applications.
Regular price
$35.99
Regular price
Sale price
$35.99
Unit price
per
Initiate Order
Premium Ball Type Check Valves - NPT Connection, Brass & Stainless Steel
$35.99
Quantity: 1
Claim Your Seller Account
Premium Ball Type Check Valves - NPT Connection, Brass & Stainless Steel
$35.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our premium Ball Type Check Valves with NPT Connection offer superior performance in controlling the flow of liquids or gases. Made from high-quality 303 SS material with a 304 SS ball, these valves ensure durability and reliability. Featuring metal-to-metal construction, they prevent reverse flow effectively. With a maximum operating pressure gauge of 200 psig and a maximum temperature of 300°F, these valves provide secure and efficient flow control. Ideal for industrial applications requiring precision and durability.
Product Specifications
Dimensions Total Length
0.880 in
Dimensions Width Across Flats Hex
9/16 in
Features Features
All metal construction Long life operation Choice of cracking pressure High pressure capability
Flow Data Air Flow At 100 Psig
331 ft³/h
Flow Data Water Flow At 100 Psig
0.8 gpm
Specifications Ball Material
304 SS
Specifications Connection A
1/8" NPT Female
Specifications Connection B
1/8" NPT Male
Specifications Cracking Pressure
0 psig
Specifications Cv
0.081
Specifications Material
303 SS
Specifications Maximum Operating Pressure Gauge
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
