Premium Ball Type NPT Check Valves Set
Premium Ball Type NPT Check Valves Set
SKU:CHE-a2f1a1
Reliable Premium Ball Type NPT Check Valves for secure one-way flow control in liquids and gases.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Premium Ball Type NPT Check Valves Set
$29.99
Quantity: 1
Claim Your Seller Account
Premium Ball Type NPT Check Valves Set
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience superior fluid control with our Premium Ball Type Check Valves Set, featuring brass and stainless steel construction for durability. Suitable for a wide range of liquids and gases, these valves ensure one-way flow while preventing reverse flow. With metal-to-metal construction and a choice of cracking pressure, enjoy reliable, high-pressure performance. Operating at temperatures up to 300°F and 200 psig, these valves provide lasting quality and minimal seat leakage. Ideal for industrial settings and compatible with 1/4" NPT connections.
Product Specifications
Dimensions Total Length
1.25 in
Dimensions Width Across Flats Hex
3/4 in
Features Features
All metal construction Long life operation Choice of cracking pressure High pressure capability
Flow Data Air Flow At 100 Psig
781 ft³/h
Flow Data Water Flow At 100 Psig
1.9 gpm
Specifications Ball Material
304 SS
Specifications Connection A
1/4" NPT Male
Specifications Connection B
1/4" NPT Female
Specifications Cracking Pressure
0 psig
Specifications Cv
0.190
Specifications Material
303 SS
Specifications Maximum Operating Pressure Gauge
200 psig
Specifications Maximum Temperature
300 ºF
Specifications Seat Leakage
20 SSCM (max.) air flow at 25 psi differential
