Premium Brass Check Valves with Fluorocarbon Seal

Name: Premium Brass Check Valves with Fluorocarbon Seal
Brand: O'Keefe Controls Co.
SKU: CHE-3a2004
Price: 39.99 USD
Availability: OutOfStock

SKU:CHE-3a2004

Precision-engineered Premium Brass Check Valves for reliable fluid control in industrial settings.

$39.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Experience superior fluid control with our Premium Brass Check Valves featuring a Fluorocarbon seal for enhanced durability. Crafted for reliability, these valves offer a tight seal, optimal flow control, and long-lasting performance. Ideal for industrial applications requiring precise pressure regulation and seamless operation. Compliant with federal procurement standards and industry certifications to meet rigorous quality demands.

Product Specifications

Dimensions Nose Diameter

5.59 mm

Dimensions Orifice Diameter

0.06 in | 1.52 mm

Dimensions Thread Size

Dimensions Total Length

16.3 mm

Dimensions Width Across Flats Hex

4 mm

Features Features

All metal construction option Long life operation Low cost

Specifications Ball Material

Fluorocarbon

Specifications Connection A

M8 Threaded Insert O-Ring seal

Specifications Cv

0.081

Specifications Hex Type

Internal

Specifications Material

Brass

Specifications Maximum Operating Pressure

875 kPa

Specifications Maximum Temperature

120 ÂºF

Specifications Nominal Orifice Size

Specifications Screened

None

Specifications Seal Material

Fluorocarbon

Specifications Seat Leakage

6 SCCM (max.) air flow at greater than 50 psi differential

Specifications Thread

Male

Premium Brass Check Valves with Fluorocarbon Seal
