Premium High Pressure Tee Fittings
Premium High Pressure Tee Fittings
SKU:FIX-b16ec2
Discover reliability and precision with our Autoclave Engineers Premium High Pressure Tee Fittings. Designed for maximum performance in high-pressure systems.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Premium High Pressure Tee Fittings
$59.99
Quantity: 1
Claim Your Seller Account
Premium High Pressure Tee Fittings
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience uncompromising performance with our Premium High Pressure Tee Fittings. Engineered by Autoclave Engineers, these fittings boast a robust construction and precision engineering to meet the demanding requirements of high-pressure systems. With a pressure rating of 43000 psi and an outside diameter tube of 25.4mm, these fittings ensure secure connections and optimal performance. The fittings come complete with appropriate glands and collars, offering a hassle-free setup and reliable operation. Trust Autoclave Engineers for quality and durability in every fitting.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Manufacturing Notes 0
For 1: Fixed center carriages will experience a reduction in preload or a slight clearance as they pass between the curves and straights on a track system, but this is rarely an issue. This clearance is detailed on 57. Please note the FCC25 159 has a larger than normal clearance. Bogie carriages 47 are not subject to clearance.For 2: Offset holes in carriage for eccentric bearings necessitate adjustment rotation in the direction shown.For 3: It is recommended that carriages are fitted with lubricators. The quantity of lubricators may be reduced in systems with many carriages or where the bleed lubrication facility is used.For 4: Dowel holes V1 define the center and may be used for location purposes. They are not included as standard on the corrosion resistant version, but are available on special request.For 5: CHK controlled height carriages use CHK bearings and are supplied in sets, matched by their E dimension. It is recommended to specify CHK for precision applications or where consistent carriage heights are important. CHK is standard for carriages with DR bearings.For 6: The W dimension is greater for carriages with floating bearings - see Wf in the table. Dimensions D and E will change for carriages with floating bearings. The amount of float is indicated by dimension B 1
Specifications Dimension A
105 mm
Specifications Dimension B
80 mm
Specifications Dimension B1
50 in
Specifications Dimension C
85 mm
Specifications Dimension C1
40 mm
Specifications Dimension C2 001
90 mm
Specifications Dimension D
30.5 mm
Specifications Dimension E
20.5 mm
Specifications Dimension F
46 mm
Specifications Dimension G
45.66 mm
Specifications Dimension H
20.45 mm
Specifications Dimension I
25.21 mm
Specifications Dimension J
16 mm
Specifications Dimension K
15.6 mm
Specifications Dimension L
14 mm
Specifications Dimension M
5.3 mm
Specifications Dimension M Depth
4.5 mm
Specifications Dimension N
3.2 mm
Specifications Dimension O
24.38 mm
Specifications Dimension P
23.01 mm
Specifications Dimension Q
22 mm
Specifications Dimension Q Depth
8.4 mm
Specifications Dimension R Hole Size F6
8 mm
Specifications Dimension R Tolerance Hole Size F6
+0.013 mm | +0.022 mm
Specifications Dimension S
2 in
Specifications Dimension T
5 mm
Specifications Dimension U
11.5 mm
Specifications Dimension V
M6
Specifications Dimension V1 K6
6 mm
Specifications Dimension V1 Tolerance K6
+0.002 mm | -0.006 mm
Specifications Dimension W
16.6 mm
Specifications Dimension Wf
18.1 mm
Specifications For Use With Ring Slides And Curved Segments
R25 351 R360/R180/R90
Specifications For Use With Track System
TR25 351
Specifications Weight
420 g
