Premium PPS PolyphenyleneSulfide Sheet
Premium PPS PolyphenyleneSulfide Sheet
SKU:SHA-e6e45e
Discover premium chemical-resistant PPS sheet with unmatched strength & dimensional stability. Ideal for high-tech applications.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Premium PPS PolyphenyleneSulfide Sheet
$99.99
Quantity: 1
Claim Your Seller Account
Premium PPS PolyphenyleneSulfide Sheet
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our Premium PPS PolyphenyleneSulfide Sheet offers unmatched chemical resistance, low moisture absorption, precise tolerance machining, excellent electrical properties, and inherent flame retardancy. With a high strength-to-weight ratio and exceptional dimensional stability, it is ideal for pump housings, chromatography components, chip nests, and more. Compliant with ASTM D 6358 and UL 94 V0 standards, this sheet is a top choice for demanding applications in laboratories, analytical equipment, and beyond.
Product Specifications
Advantages 0
High Strength.Excellent chemical & hydrolysis resistance.Very good dimensional stability.Excellent wear & frictional behavior.Inherent low flammability. Excellent alternative to PEEK at lower temperatures.Good electrical insulating & dielectric properties.Essentially zero moisture absorption.
Applications 0
Pump housings.High pressure liquid Chromatography components.Chip nests.Retaining rings.Wafer Carriers.Laboratory & Analytical Equipment.
Specifications Astm Shape Spec
ASTM D 6358
Specifications Availability
3-4 weeks
Specifications Coefficient Of Friction Dynamic
.40
Specifications Color
Off-white
Specifications Dielectric Strength
540 V/mil
Specifications Flammability Rating Ul 94
V0 (.125")
Specifications Flexural Modulus
575000 psi
Specifications Flexural Strength
21000 psi
Specifications Hardness Durometer Shore D
85
Specifications Heat Deflection Temperature 264 Psi
250 ºF
Specifications Impact Strength Notched
.60 ft·lb/in
Specifications Material
PPS
Specifications Maximum Operating Temperature
425 ºF
Specifications Minimum Order
1
Specifications Optional Sheet Size
12"x48"⢠24"x48"
Specifications Sheet Size
12 x 12 in
Specifications Specific Gravity
1.35
Specifications Tensile Strength
13500 psi
Specifications Thickness
2.250 in
Specifications Tolerance
+only in
Specifications Weight
1.76 lb/ft²
