Premium Stainless Steel U Coils - UC Series
Premium Stainless Steel U Coils - UC Series
SKU:HEA-74e9e1
High-performance stainless steel U Coils for precise heating or cooling in alkaline or acid solutions. Rugged construction, leak-free operation, high pressure rating.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
Premium Stainless Steel U Coils - UC Series
$149.99
Quantity: 1
Claim Your Seller Account
Premium Stainless Steel U Coils - UC Series
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Premium Stainless Steel U Coils from the UC Series offer superior chemical resistance and outstanding performance for heating or cooling applications in alkaline or acid solutions. Featuring rugged construction with heavy wall 316 stainless steel tubing, these coils ensure leak-free operation with high pressure ratings, making them ideal for small tanks with low heat exchange requirements. With options for special configurations, lengths, and various alloys available, these coils provide unmatched durability and efficiency for institutional and consumer needs.
Product Specifications
Features And Benefits Features And Benefits
SUPERIOR CHEMICAL RESISTANCE: Wide variety of materials available for use in heating or cooling applications for alkaline or acid solutions and rinse tanks. Check solution guide or consult with your chemical supplier for proper sheath material.RUGGED CONSTRUCTION:Heavy wall, 18-gauge metal tubing available in steel, 316 stainless steel, and titanium.1â diameter tubing.1â MNPT fittings standard.OUTSTANDING PERFORMANCE: One-inch thick, low profile design. Every inch of coil surface is active exchange area. Ideal for small tanks with low heat exchange requirements.LEAK-FREE OPERATION: Single point connections reduce the potential for leaks and simplifies installation. One-inch MNPT connections standard.HIGH PRESSURE RATING: 100 PSI working pressure (steam or water).SIZES: .75 square ft. to 2.5 square ft. of exchange area standard.OPTIONS AVAILABLE (consult factory):Special configurations and lengths.Heavier gauge tubing.Zirconium, Hastelloy C® and other alloys available.Fluoropolymer coatings for corrosion protection at solution/atmospheric interface.Non-conductive isolator couplings.L-shaped configurations for bottom heat applications.Higher pressure ratings available.Hastelloy C® is a registered trademark of Haynes International, Inc.
Specifications Available Tubing
1/2 " | 5/8 " | 3/4 " | 1 " | 1-1/4 "
Specifications Depth
18 " | 457 mm
Specifications Exchange Area
0.75 ft²
Specifications Manufacturer
Process Technology
Specifications Material
316 Stainless Steel
Specifications Shipping Weight
3.0 Pound
Specifications Weight
3.0 lbs | 1.4 kg
Specifications Width
12 " | 305 mm
