Premium Ultrafine Graphite for EDM Applications
Premium Ultrafine Graphite for EDM Applications
SKU:ELE-79083d
Maximize EDM efficiency with our Ultrafine Graphite: exceptional strength, precise details, superior finishes guaranteed.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Premium Ultrafine Graphite for EDM Applications
$29.99
Quantity: 1
Claim Your Seller Account
Premium Ultrafine Graphite for EDM Applications
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Elevate your EDM processes with our Ultrafine Graphite, meticulously engineered for Electrical Discharge Machining (EDM). Our EDM-4 variant sets the gold standard in ultrafine grain classification with exceptional strength, optimal hardness, and unmatched electrode fabrication capabilities. With average particle size < 4 µ, flexural strength of 17500 psi, compressive strength of 21500 psi, Shore hardness of 76, and electrical resistivity of 500 µin, this graphite ensures superior EDM performance, enhancing metal removal rates, wear resistance, and surface finish quality. Ideal for detailed electrode EDMing and wire cut electrodes, plus perfect for plastic injection molds.
Product Specifications
Applications
EDMing of fine detailed electrodes requiring excellent surface finishesWire cut electrodesPlastic injection molds
Specifications Average Particle Size
< 4 µ
Specifications Compressive Strength
21500 psi | 1511 kg/cm²
Specifications Electrical Resistivity
500 µin | 12.7 µm
Specifications Flexural Strength
17500 psi | 1230 kg/cm²
Specifications Shore Hardness
76
