Process Technology HXFL Series PTFE Immersion Heaters
Process Technology HXFL Series PTFE Immersion Heaters
SKU:HEA-a027ca
High-performance Process Technology HXFL Series PTFE Heaters for industrial applications. CE, CSA, and UL Listed.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
Process Technology HXFL Series PTFE Immersion Heaters
$349.99
Quantity: 1
Claim Your Seller Account
Process Technology HXFL Series PTFE Immersion Heaters
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Process Technology HXFL Series Low Profile L-Shaped Fluoropolymer (PTFE) Heaters are designed for high-performance heating in industrial applications. Featuring a sturdy stainless steel construction with a grounded wire, these heaters provide reliable heat transfer with a watt density of 10 W/in². With options for different thermal protectors, including resettable options for varying solution temperatures, these heaters ensure safe and efficient operation. Recommended guards offer additional protection, and the CE, CSA, and UL listings attest to the quality and compliance of these heaters.
Product Specifications
Specifications Certifications
CE | CSA | UL Listed
Specifications Construction
Ground wire is welded to stainless steel sheath.
Specifications Diameter
9 " | 229 mm
Specifications Guards Recommended
Standard guard is polypropylene. Fluoropolymer (PTFE) guards recommended for chromic acid and solutions exceeding 180º F (82ºC).
Specifications Guard Model Number
HXFL09-R*G
Specifications Horizontal Length
9 " | 229 mm
Specifications Manufacturer
Process Technology
Specifications Material
Fluoropolymer
Specifications Max Cold Zone
35 " | 889 mm
Specifications Options Available
Comes Standard with Replaceable thermal protector: P1: for solutions up to 180°F (82°C). | Resettable thermal protector: P2: for solutions up to 180°F (82°C). | Resettable thermal protector: P3: for solutions up to 250°F (121°C). | Resettable thermal protector: P8: for solutions up to 210°F (99°C).
Specifications Phase
Single
Specifications Series
HXFL
Specifications Shipping Weight
13.0 Pound
Specifications Standard Vertical Length
18 " | 457 mm
Specifications Volts
240 V
Specifications Watts
3000 W
Specifications Watt Density
10 W/in² | 1.5 W/cm²
Specifications Weight
13.0 lbs | 5.9 kg
