Process Technology HXO Series PTFE Heaters with Thermal Protection
Process Technology HXO Series PTFE Heaters with Thermal Protection
SKU:HEA-20fde4
Discover reliable HXO Series PTFE Heaters with thermal protection for industrial heating applications. CE and UL Listed for safety.
Regular price
$599.99
Regular price
Sale price
$599.99
Unit price
per
Initiate Order
Process Technology HXO Series PTFE Heaters with Thermal Protection
$599.99
Quantity: 1
Claim Your Seller Account
Process Technology HXO Series PTFE Heaters with Thermal Protection
$599.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The HXO Series Fluoropolymer (PTFE) Heaters by Process Technology offer exceptional heating performance with thermal overload protection options. Designed for industrial applications, these heaters feature a high watt density of 10 W/in² for efficient heating. With certifications including CE and UL Listed, these heaters ensure safety and compliance. The replaceable thermal protectors allow flexibility for different solution temperatures, making them ideal for a wide range of process heating needs. Ensure proper guard protection with customizable options to meet specific requirements.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Certifications
CE | UL Listed
Specifications Guards Recommended
Standard guard is polypropylene. Fluoropolymer (PTFE) guards recommended for chromic acid and solutions exceeding 180º F (82ºC).
Specifications Guard Model Number
HXO06-10-17G
Specifications Hot Zone
10 " | 254 mm
Specifications Manufacturer
Process Technology
Specifications Material
Fluoropolymer (PTFE)
Specifications Max Cold Zone
35 " | 889 mm
Specifications Options Available
Comes Standard with Replaceable thermal protector: P1: for solutions up to 180°F (82°C). | Resettable thermal protector: P2: for solutions up to 180°F (82°C). | Resettable thermal protector: P3: for solutions up to 250°F (121°C). | Resettable thermal protector: P8: for solutions up to 210°F (99°C).
Specifications Overall Length
17 " | 432 mm
Specifications Phase
Single
Specifications Series
HXO
Specifications Shipping Weight
8.0 Pound
Specifications Std Cold Zone
7 " | 178 mm
Specifications Volts
480 V
Specifications Watts
2000 W
Specifications Watt Density
10 W/in² | 1.5 W/cm²
Specifications Weight
8.0 lbs | 3.6 kg
Specifications Width
6 " | 152 mm
