Process Technology Metal Heaters - Titanium Series
Process Technology Metal Heaters - Titanium Series
SKU:HEA-5a306c
Premium Metal Heaters for Industrial Use - Superior Chemical Resistance, High Watt Densities, Grounded Construction
Regular price
$899.99
Regular price
Sale price
$899.99
Unit price
per
Initiate Order
Process Technology Metal Heaters - Titanium Series
$899.99
Quantity: 1
Claim Your Seller Account
Process Technology Metal Heaters - Titanium Series
$899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Process Technology Metal Heaters in the Titanium Series offer exceptional performance for industrial applications. With watt densities up to 35 watts per square inch, these heaters ensure a long service life and superior chemical resistance in aqueous alkaline solutions. Featuring rugged construction with heavy wall metal sheaths available in steel, 304 stainless steel, 316 stainless steel, and titanium, these heaters are cULus listed and CE compliant. The corrosion-resistant head and safety features like grounded construction and built-in thermal protector make them a reliable choice for demanding environments.
Product Specifications
Features And Benefits Features And Benefits
SUPERIOR CHEMICAL RESISTANCE: For use in most aqueous alkaline solutions, plating and phosphate tanks. Check solution recommendation chart with your chemical supplier for proper sheath material selection.RUGGED CONSTRUCTION: Heavy wall metal sheaths available in: steel, 304 stainless steel, 316 stainless steel, Titanium.OUTSTANDING PERFORMANCE: Watt densities up to 35 watts per square inch (5.4 w/cm2) ensure long service life.CORROSION RESISTANT HEAD: Vapor resistant, flame retardant polypropylene terminal enclosure with 3 ft (.9m) flexible PVC liquid tight conduit.SAFETY FEATURES:Grounded construction.Thermal protector built in. Replaceable P1 protector standard for solutions up to 180°F (82°C).Non-floating construction.CERTIFICATIONS: cULus listed (except steel) and CE compliant (except 600 volts).SIZES: 1,000 watts to 12,000 watts.VOLTAGES: 120 to 600 volts.OPTIONS AVAILABLE (consult factory):Replaceable thermal protectors:P4: for solutions up to 230°F (110°C).P5: for solutions up to 300°F (149°C).Resettable thermal protectors:P2: for solutions up to 180°F (82°C).P6: for solutions up to 230°F (110°C).P7: for solutions up to 300°F (149°C).Special configurations and lengths.Longer wire and conduit lengths.Lower watt densities for highly viscous solutions.All metal welded junction box.Temperature and level controls sized to match the heater (sold separately).
Options Available Options Available
Comes Standard with Replaceable thermal protector: P1: for solutions up to 180°F (82°C). | Replaceable thermal protector: P4: for solutions up to 230°F (110°C). | Replaceable thermal protector: P5: for solutions up to 300°F (149°C). | Resettable thermal protector: P2: for solutions up to 180°F (82°C). | Resettable thermal protector: P6: for solutions up to 230°F (110°C). | Resettable thermal protector: P7: for solutions up to 300°F (149°C).
Specifications Certifications
cUL US Listed
Specifications Hot Zone
49 " | 1245 mm
Specifications Manufacturer
Process Technology
Specifications Material
Titanium
Specifications Overall Length
59 " | 1499 mm
Specifications Phase Available
Single (Standard) | Three
Specifications Shipping Weight
25.0 Pound
Specifications Volts
480 V
Specifications Watts
10000 W
Specifications Weight
25.0 lbs | 11.3 kg
