PVC Impact-Resistant Type II Light Gray Sheet
PVC Impact-Resistant Type II Light Gray Sheet
SKU:SHA-515e16
High-quality PVC Impact-Resistant Type II Sheet with excellent chemical resistance, mechanical strength, and ASTM/UL certifications.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
PVC Impact-Resistant Type II Light Gray Sheet
$89.99
Quantity: 1
Claim Your Seller Account
PVC Impact-Resistant Type II Light Gray Sheet
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PVC Impact-Resistant Type II Light Gray Sheet is a high-quality material designed for applications requiring excellent chemical resistance, mechanical strength, and dimensional stability. This polyvinyl chloride sheet meets ASTM D1784, Class 16444-D and UL94 V0 standards, ensuring high impact corrosion resistance. With a 48 x 96 in sheet size, 0.062 in thickness, and exceptional properties such as 7400 psi tensile strength, 179 °F heat deflection temperature, and 645 V/mil dielectric strength, this sheet is versatile and reliable for various uses. Whether for thermal forming, shock resistance, or physical abuse, this PVC Type II sheet is a top choice for durability and performance.
Product Specifications
Specifications Density Astm D792
1.35 gm/cc
Specifications Dielectric Strength Astm D149
645 V/mil
Specifications Flame Spread E84
15
Specifications Flammability Rating Ul 94
V0
Specifications Flexural Modulus
400000 psi
Specifications Flexural Strength
10000 psi
Specifications Hardness Durometer Shore D
85
Specifications Hardness Rockwell Astm D785
R106
Specifications Heat Deflection Temperature 264 Psi
179 ºF
Specifications Izod Impact Strength Astm D256
18 ft·lb/in
Specifications Optional Sheet Size
12 x 24 | 12 x 36 | 24 x 120 | 24 x 24 | 24 x 96 | 36 x 48 | 48 x 48 | 48 x 72 | 60 x 120
Specifications Sheet Size
48 x 96 in
Specifications Tensile Modulus Astm D638
396000 psi
Specifications Tensile Strength Astm D638
7400 psi
Specifications Thickness
0.062 in
Specifications Vicat Softening Point Astm D1525
181 ºF
Specifications Water Absorption 24 Hrs 73f Astm D570
0.16 %
Specifications Weight
0.469 lb/ft²
