PVC Light Gray Sheet - Type II 5.000 in Thick, 12 x 12 in
PVC Light Gray Sheet - Type II 5.000 in Thick, 12 x 12 in
SKU:SHA-d7cc57
High-quality PVC Type II Light Gray Sheet with superior impact and corrosion resistance, ideal for diverse applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
PVC Light Gray Sheet - Type II 5.000 in Thick, 12 x 12 in
$49.99
Quantity: 1
Claim Your Seller Account
PVC Light Gray Sheet - Type II 5.000 in Thick, 12 x 12 in
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PVC Type II Light Gray Sheet offers exceptional chemical resistance, high impact corrosion resistance, and excellent mechanical strength. This polyvinyl chloride sheet is ideal for applications requiring thermal forming and durability against physical abuse. Compliant with ASTM D1784 and UL94 V0 standards, it exhibits a hardness of 85 Durometer Shore D, tensile strength of 7400 psi, and a Vicat Softening Point of 181°F. With a Flame Spread rating of 15 and dielectric strength of 645 V/mil, this sheet ensures reliability and safety in various environments.
Product Specifications
Specifications Density Astm D792
1.35 gm/cc
Specifications Dielectric Strength Astm D149
645 V/mil
Specifications Flame Spread E84
15
Specifications Flammability Rating Ul 94
V0
Specifications Flexural Modulus
400000 psi
Specifications Flexural Strength
10000 psi
Specifications Hardness Durometer Shore D
85
Specifications Hardness Rockwell Astm D785
R106
Specifications Heat Deflection Temperature 264 Psi
179 ºF
Specifications Izod Impact Strength Astm D256
18 ft·lb/in
Specifications Optional Sheet Size
12 x 24 | 12 x 36 | 24 x 120 | 24 x 24 | 24 x 96 | 36 x 48 | 48 x 48 | 48 x 72 | 60 x 120
Specifications Sheet Size
12 x 12 in
Specifications Tensile Modulus Astm D638
396000 psi
Specifications Tensile Strength Astm D638
7400 psi
Specifications Thickness
5.000 in
Specifications Vicat Softening Point Astm D1525
181 ºF
Specifications Water Absorption 24 Hrs 73f Astm D570
0.16 %
Specifications Weight
37.50 lb/ft²
